Onix Plus™ Floorbox with Edge Cord Outlet Lid
ROBUST CORD CAPS*
l Designed for improved retention
ATTRACTIVE, AESTHETIC LIDS
l Stylishly designed
l Lid options allow for various floor coverings
to be used
*Cord Outlet Lids are not suitable for Wet Wash applications.
DESIGNED FOR USE WITH CABLELINK PLUS SCREED SYSTEM
ROBUST LOAD PLATE
l Superior load bearing
performance
l Ideal for areas of heavy foot
traffic
l A tile lifter should be used
to lift all Onix Plus lids
TESTED TO EN50085-2-2
TO ACCEPT 10,000N LOAD
COMPARTMENT SEGREGATION
l Set at 35mm
as standard
l Height adjustable
– 25 to 45mm with
appropriate CUBA kit
l Deeper Screed depths
have fixed wiring spaces
STAGGERED PLATE
l Provides strain relief clearance
for moulded plug tops
l Stagger only available
with 3 and 4 compartment
floorboxes
BASE FIXING FEET
l ‘Fast fix’ installation
OUTLET BOX
l Option of two screed depths: 55-80mm and 80-110mm
l Flat sided base design ensures a stronger screed
solution and faster taping
l Deeper screed depths available on request
