283 / 759
Industrial 10kA RCDs
Four Pole
Type AC
25 AMP
FOUR MODULE
40 AMP
FOUR MODULE
6425s
1
25A 230/400V
30mA TRIPPING CURRENT
Suitable for installation in Sentry four module
enclosures and Commando Combi.
Positive contact status indication in accordance
with 17th Edition IET Wiring Regulations
(537.2.2.2 and 537.3.2.2)
DIMENSIONS:
85 x 72 x 75mm
CABLE CAPACITY:
50mm
2
BS EN 61008:1995
6440s
1
40A 230/400V
30mA TRIPPING CURRENT
6240s
1
40A 230/400V
100mA TRIPPING CURRENT
6440s
6240s
6425s
Industrial 10kA
RCDs
Time Delayed
Double Pole
6216s
1
16A 230V
10mA TRIPPING CURRENT
6630s
1
32A 230V
30mA TRIPPING CURRENT
5640s
1
40A 230V
30mA TRIPPING CURRENT
5660s
1
63A 230V
30mA TRIPPING CURRENT
Suitable for installation in Sentry Consumer Units
and two or four module enclosures.
Positive contact status indication in accordance
with 17th Edition IET Wiring Regulations
(537.2.2.2 and 537.3.2.2)
DIMENSIONS:
85 x 36 x 75mm
CABLE CAPACITY:
50mm
2
BS EN 61008:1995
6980s
1
80A 230V
100mA TRIPPING CURRENT
TIME DELAYED
6400s
1
100A 230V
100mA TRIPPING CURRENT
TIME DELAYED
Suitable for installation in Sentry Consumer
Units and Four Module enclosures. When used
as a mains incomer these units will provide
discrimination with downstream instantaneously
operating 10mA or 30 mA RCD’s. For example,
they can be used as main incomers on split load
consumer units where it is not desirable, because
of the possibility of unwanted tripping, to place
all of the circuits on an instantaneous 30mA
RCD, but where earth leakage protection is still
required for these circuits or where compliance
is required to the indirect contact protection
requirements of the IET Wiring Regulations.
DIMS: 81 x 36 x 76mm
CABLE CAPACITY: 50mm
2
BS EN 61008:1995
NOT TO BE USED FOR PERSONAL PROTECTION
AGAINST ELECTRIC SHOCK
FACTORY BUILT SERVICE
MK can save you time and money by
pre-assembling consumer units with your
required Sentry components
6980s
6400s
6216s
6630s
5640s
TWO MODULE
Industrial 10kA RCDs
Pulsating d.c.
Fault Current Sensitive
Double Pole Type A
TWO MODULE
MK Electric Catalogue
283
Technical Hotline
+44 (0)1268 563720
CIRCUIT PROTECTION
Sentry
