285 / 759
DIGITAL
TWO CHANNEL
TWO MODULE
5732s
1
24 HOUR/7 DAY
DISPLAY
MIN SETTING 1
MINUTE
Pre-programmed with
UK time and automatic
summer/winter
adjustment.
Provides 50
programming selections.
Freely selectable day
grouping facility. Manual
override, winter/summer
time adjustment.
Power reserve of 3 years.
Suitable for DIN-rail
mounting in Sentry
Consumer Units and
two or four module
enclosures.
VOLTAGE RATING:
240V 50/60Hz
CURRENT RATING:
Resistive load 16A
Inductive load 2.5A
Tungsten lamps 5A
(1000W)
Fluorescent lamps 1000W
DIMENSIONS:
85 x 36 x 68mm
CABLE CAPACITY:
2 x 2.5mm
2
or 4 x
1.5mm
2
EN 60730-2-7:1993
SYNCHRONOUS
THREE MODULE
QUARTZ
STABILISED
THREE MODULE
SYNCHRONOUS
ONE MODULE
DIGITAL
ONE CHANNEL
TWO MODULE
DIGITAL
ONE CHANNEL
ONE MODULE
5707s
1
7 DAY DIAL
MIN SETTING 3
HOURS
5724s
1
24 HOUR DIAL
MIN SETTING 30
MINUTES
Suitable for DIN rail
mounting in Sentry
Consumer Units or four
module enclosures.
VOLTAGE RATING:
220-240Va.c. 50Hz
CURRENT RATING:
Resistive load 16A
Inductive load 4A
Tungsten lamps 6A
(1350W)
Fluorescent lamps 1350W
DIMENSIONS:
85 x 54 x 68mm
CABLE CAPACITY:
2 x 2.5mm
2
or
4 x 1.5mm
2
5824s
1
24 HOUR DIAL
MIN SETTING 30
MINUTES
Suitable for DIN rail
mounting in Sentry
Consumer Units and
two or four module
enclosures.
Power reserve 150 hours
VOLTAGE RATING:
220-240Va.c. 50-60Hz
CURRENT RATING:
Resistive load 16A
Inductive load 4A
Tungsten lamps 6A
(1350W)
Fluorescent lamps
1350W
DIMENSIONS:
85 x 54 x 68mm
CABLE CAPACITY:
2 x 2.5mm
2
or 4 x
1.5mm
2
EN 60730-2-7:1993
5833s
1
24 HOUR DIAL
MIN SETTING 30
MINUTES
Suitable for DIN rail
mounting in Sentry
Consumer Units and
two or four module
enclosures
VOLTAGE RATING:
240V 50Hz
CURRENT RATING:
Resistive load 16A
Inductive load 4A
Tungsten lamps 6A
(1350W)
Fluorescent lamps 1350W
DIMENSIONS:
90 x 18 x 68mm
CABLE CAPACITY:
2 x 2.5mm
2
or 4 x
1.5mm
2
EN 60730-2-7:1993
5731s
1
24 HOUR/7 DAY
DISPLAY
MIN SETTING 1
MINUTE
Pre-programmed with
UK time and automatic
summer/winter
adjustment.
Provides 50
programming selections.
Freely selectable day
grouping facility. Manual
override, winter/summer
time adjustment.
Power reserve of 3 years.
Suitable for DIN-rail
mounting in Sentry
Consumer Units and
two or four module
enclosures.
VOLTAGE RATING:
240V 50/60Hz
CURRENT RATING:
Resistive load 16A
Inductive load 2.5A
Tungsten lamps 5A
(1000W)
Fluorescent lamps
1000W
DIMENSIONS:
85 x 36 x 68mm
CABLE CAPACITY:
2 x 2.5mm
2
or 4 x
1.5mm
2
EN 60730-2-7:1993
5733s
1
24 HOUR DIAL
MIN SETTING 1
MINUTE
Provides 50
programming selections.
Freely selectable day
grouping facility. Manual
override, winter/summer
time adjustment, holiday
programme and random
generator are standard
facilities.
Power reserve of 150
hours.
Suitable for DIN rail
mounting in Sentry
Consumer Units and
two or four module
enclosures
VOLTAGE RATING:
240V 50/60Hz
CURRENT RATING:
Resistive load 16A
Inductive load 2.5A
Tungsten lamps 5A
(1000W)
Fluorescent lamps
1000W
DIMENSIONS:
90 x 18 x 74mm
CABLE CAPACITY:
2 x 2.5mm
2
or 4 x
1.5mm
2
EN 60730-2-7:1993
5824s
5731s
5733s
5833s
5707s
5724s
5732s
5711s
1
RATING 1A AT 8V
PRIMARY
220 – 240V A.C.50HZ
Suitable for installation in
Sentry Consumer Units
and two or four module
enclosures.
NOTE:
When installed in a
consumer unit, ensure
that output cables
inside the enclosures
are suitable for a 230V
environment, either by
sleeving the bell wire to
BS 2848 or using 230V
cable.
Complete with terminal
covers. Also suitable for
surface mounting.
DIMENSIONS:
88 x 36 x 67mm
CABLE CAPACITY:
1 x 2.5mm2
EN 61558-2-8
5711s
TWO MODULE
Bell
Transformer
Time Switches
MK Electric Catalogue
285
