perimeter and distribution
|
cable management
29
Data Trunking System
Dimensions (mm)
45mm
160mm
45mm
140mm
(X)
2
1
1
(X)
1
Pro"les
Compartment CSA mm
2
1 = 742
2 = 1431
*(X) = 3035
DADO
EXTENDED DADO
Assembly
Dado = 1.20 Kg/m
Extended Dado = 1.35 Kg/m
Wall Thickness
VCT100 = 1.7mm
VCT110 = 1.7mm
VCT120 = 1.7mm
VCT140 = 2.0mm
VCT160 = 2.0mm
CABLE CAPACITY
Compartment 1
Compartment 2
Compartment (X)
Full Term CSA (mm
2
)
742
1431
3035
Type of
Size
Cable
Term at 45% fill (mm
2
)
conductor
factor
333
643
1365
Power cables
Number of cables at 45% fill
1.5mm
2
8.6
38
74
158
PVC
2.5mm
2
12.6
26
51
108
stranded
4mm
2
16.6
20
38
82
6mm
2
21.2
15
30
64
Data cables
Number of cables at 45% fill (a) and full capacity (b)
a
b
a
b
a
b
Cat 5E UTP 5.5mm dia. 30.2
11
24
21
47
45
100
Cat 5E STP 6.0mm dia. 36.0
9
20
17
39
37
84
Cat 6 UTP 6.5mm dia. 42.2
7
17
15
33
32
71
Cat 6 STP 7.0mm dia. 49.0
6
15
13
29
27
61
Cat 7
8.0mm dia. 64.0
5
11
10
22
21
47
* Compartment (X) dimensions and capacity are given as guide only for instances where trunking is used for cable routing e.g. vertical drops/risers.
VCT140
VCT110
VCT100
VCT110
VCT110
VCT100
VCT120
VCT160
VCT140
