perimeter and distribution
|
cable management
25
Prestige
3D
Dado & Skirting
Technical
Dimensions (mm)
Component selection guide
57mm
170mm
2
1
1
57mm
170mm
2
3
1
CABLE CAPACITY
Compartment 1
Compartment 2 Compartment 2 with 45mm deep box
Compartment 3
Full Term CSA (mm
2
)
1763
3828
610
1952
Type of
Size
Cable
Term at 45% fill (mm
2
)
conductor
factor
793
1722
274
878
Power cables
Number of cables at 45% fill
1.5mm
2
8.6
92
200
31
102
PVC
2.5mm
2
12.6
62
136
21
69
stranded
4mm
2
16.6
47
103
16
52
6mm
2
21.2
37
81
12
41
Data cables
Number of cables at 45% fill (a) and full capacity (b)
a
b
a
b
a
b
a
b
Cat 5E UTP 5.5mm dia. 30.2
26
58
57
126
9
20
29
64
Cat 5E STP 6.0mm dia. 36.0
22
48
47
106
7
16
24
54
Cat 6 UTP
6.5mm dia. 42.2
18
41
40
90
6
14
20
46
Cat 6 STP
7.0mm dia. 49.0
16
35
35
78
5
12
17
39
Cat 7
8.0mm dia 64.0
12
27
26
59
4
9
13
30
Pro"les
Compartment CSA mm
2
1 = 1763
2 = 3828
3 = 1952
Assembly
Dado = 1.58 kg/m
Skirting = 1.60 kg/m
Wall Thickness
VP100 = 1.7mm
VP110 = 1.7mm
VP115 = 1.7mm
VP180 = 2.0mm
VP180 WHI / CHA
VP110 WHI / CHA
VP100 WHI / CHA
VP110 WHI / CHA
VP180 WHI / CHA
VP110 WHI / CHA
VP100 WHI / CHA
VP115 WHI / CHA
Data Trunking System
Dado
Skirting
Dado
Skirting
