cable management
|
perimeter and distribution
www.mkelectric.co.uk26
Prestige
3D
Dado & Skirting
Technical
Data Trunking System
Component selection guide
A
A
B
B
Flat angles and tees
D
B
A
C
Internal Corner
Dado - VP181 WHI / CHA
Skirting - VP191 WHI / CHA
End Cap
Dado - VP183 WHI / CHA
Skirting - VP193 WHI / CHA
External Corner
Dado - VP182 WHI / CHA
Skirting - VP192 WHI / CHA
Joint Cover
Dado - VP184 WHI / CHA
Skirting - VP194 WHI / CHA
FLAT ANGLES AND TEES DIMENSIONS (mm)
LIST NO
DESCRIPTION A
B
C
D
VP185 WHI / CHA Flat Angle
218mm
170mm
VP187 WHI / CHA Flat Tee
202mm
170mm
235mm
170mm
VP195 WHI / CHA Flat Angle Up
218mm
170mm
VP196 WHI / CHA Flat Angle Down 270mm
170mm
VP197 WHI / CHA Flat Tee Up
202mm
170mm
235mm
170mm
Flat Tee Up
Dado - VP187 WHI / CHA
Skirting - VP197 WHI / CHA
20
70
13
13
Flat Tee Down
Dado - VP187 WHI / CHA
20
70
13
13
20
70
13
13
Flat Angle Up
Dado - VP185 WHI / CHA
Skirting - VP195 WHI / CHA
Flat Angle Down
Dado - VP185 WHI / CHA
Skirting - VP196 WHI / CHA*
20
70
13
13
*This item is fabricated rather than moulded
