Features:
• Integral incoming metering available as
standard
• Add on metering option available
• Horizontal lighting & power metering available
• MID meter kits for billing purposes available
• Internal diameter of each ct is 21mm
Type
External Dimensions
Order No
H x W x D (mm)
List
Pack
Price
Weight
Price
Unit
Group 1 item (kg)
Integral Meter Pack*
125A ct op. 3ph 4w Energy Meter Pack - Std
125A ct op. 3ph 4w Energy Meter Pack - MID
1
045
2.27
1
045
1.69
8GP1 921-2DA80
8GP1 991-2DA80
Contains: Digital meter offering Amps,Volts, kWh readout
plus pulsed output. 3 ct's, fuses & cable loom
(the latter supplied loose for connection by others)
Add-on Meter Pack in Enclosure
* Not recommended for use with incomers mtd in the lower incomer position
i.e. rccb incomer, 4P Sw Disconnectors or 5TT8 814 TP Switch Disconnector.
125A ct op. 3ph 4w Energy Meter Pack - Std
125A ct op. 3ph 4w Energy Meter Pack - MID
1
045
6.21
1
045
6.21
8GP1 990-2DA10
8GP1 991-2DA10
Dims:
245 430
155
Contains: Digital meter offering Amps,Volts, kWh readout
plus pulsed output. 3x125A ct's, fuses & associated cable
loom
Horizontal Lighting & Power Board Metering
125A ct op.Twin 3ph 4w Energy Meter Pack -Std
125A ct op.Twin 3ph 4w Energy Meter Pack -MID
1
045
1
045
8GP1 992-2DA10
8GP1 993-2DA10
Dims:
410
860
155
Contains: Common 125A TP Sw Disconnector,
2 Digital meters offering Amps,Volts,
kWh readout plus pulsed output. 125A ct's, fuses &
associated cable loom
Common Add-on Enclosures for 125A & 200A Distribution Boards
Modular Device Extension Boxes
1 row x 18 mod wide Extension Box (245mmH)
2 row x 18 mod wide Extension Box (410mmH)
3 row x 18 mod wide Extension Box (570mmH)
4 row x 18 mod wide Extension Box (735mmH)
5 row x 18 mod wide Extension Box (815mmH)
1
045
6.56
1
045
8.23
1
045
11.07
1
045
12.70
1
045
14.40
8GP1 901-0DA10
8GP1 902-0DA10
8GP1 903-0DA10
8GP1 904-0DA10
8GP1 905-0DA10
Service Centre - 18 mod
Service Centre - 36 mod
1
045
4.10
1
045
4.10
8GP1 995-0DA13
8GP1 995-0DA14
Cable Spreader Box (245mmH)
1
045
4.50
8GP1 910-0DA10
Contains: Main Neutral & Earth Bars, along with the
provision for additional 'mini' Neutral & Earth Bars.
125A Metering Options & Common Add-on Enclosures
Distribution Boards
