Features:
• Type tested to BS EN 60439-3
• 16kA Conditional short circuit rating
• Rated Voltage 230V 50/60Hz
• Incomer(s) provided as standard
• Modular Construction
• Top, bottom & side entry
• Colour: Siemens light grey to RAL 7035
• Degree of Protection: IP2XC
• Comb busbar system
• Earth & Neutral Bars supplied as standard
• Full DIN rail supplied as standard
• User defined Split Load Units
Type
External Dimensions Order No
H x W x D (mm)
List
Pack
Price
Weight
Price
Unit
Group 1 item (kg)
All insulated
Main Switch All Insulated Consumer Units with 100A Incomer
5 way
230 190 120
8 way
230 243 120
11 way
230 294 120
14 way
230
344
120
19 way
230 439 120
1
045
2.20
1
045
2.85
1
045
3.11
1
045
3.40
1
045
4.00
1
045
1.24
1
045
1.40
1
045
1.34
1
045
1.39
1
045
2.09
1
045
3.08
1
045
3.95
1
045
4.00
1
045
1.95
1
045
2.12
1
045
2.70
8GB1 335-1DA
8GB1 335-2DA
8GB1 335-3DA
8GB1 335-4DA
8GB1 335-5DA
Metal Clad
Main Switch Metalclad Consumer Units with 100A Incomer
5 way
210 188 122
8 way
210 242 122
11 way
210 292 122
14 way
210
343
122
19 way
210 439 122
8GB3 335-1DA
8GB3 335-2DA
8GB3 335-3DA
8GB3 335-4DA
8GB3 335-5DA
User defined Split Load Metalclad Consumer Unit with 100A
Main Switch incomer and 80A 30mA rccb
9 way
210 292 122
12 way
210 343 122
17 way*
210 439 122
* A minimum of 5 outgoing ways is
recommended on the main switch circuit
* A minimum of 5 outgoing ways is
recommended on the main switch circuit
8GB3 335-6DA
8GB3 335-7DA
8GB3 335-8DA
User defined Split Load All Insulated Consumer Unit with 100A
Main Switch incomer and 80A 30mA rccb
9 way
230 294 120
12 way
230 344 120
17 way*
230 439 120
8GB1 335-6DA
8GB1 335-7DA
8GB1 335-8DA
Selection and ordering data
All Insulated & Metalclad Surface Mounting
Consumer Units
