200A Type B Surface Mounting
Distribution Boards
Features:
• Type Tested & ASTA certified to IEC 61439-2
• 16kA for 0.1 second short circuit rating
• 25kA conditional short circuit rating (Icc) to
IEC 61439-2 when used with 5SY8 mcb's
• 250A rated busbar assembly
• Rated Voltage 230/400V 50/60Hz
• Integral meter reading facility
• Modular Construction
• 1mm Sheet Steel Enclosure
• Colour: Siemens light grey to RAL 7035
• Degree of Protection: IP3X
• Shrouded outgoing neutral terminals
• Top & Bottom entry via undrilled removable
gland plates
ALPHA BS II
** For use with 200A 16,20 & 24 wayTP&N
Distribution Boards only
Type
External Dimensions Order No
H x W x D (mm)
200A rated Distribution Boards
4 way
769 430 155
6 way
823 430 155
8 way
877 430 155
12 way
985 430 155
16 way
1093 430 155
20 way
1201 430 155
24 way
1309 430 155
8GP1 204-4DA54
8GP1 206-4DA54
8GP1 208-4DA54
8GP1 212-4DA54
8GP1 216-4DA54
8GP1 220-4DA54
8GP1 224-4DA54
Distribution Board Extension Unit**
12 way Add-on 200A TP&N Distribution Board
200A Vertical Connection Kit (for the above)
8GP1 937-4DA50
8GP1 981-4DA10
Incomer Kits for the above
200A TP Switch Disconnector c/w N Link
200A TP mccb c/w N Link
200A 4P Switch Disconnector
200A 4P mccb
250A Direct Connection Kit - 120mm
2
cable
8GP1 643-4DA40
8GP1 617-0DA41
8GP1 643-4DA50
8GP1 618-0DA51
8GP1 867-0DA10
List
Pack
Price
Weight
Price
Unit
Group 1 item (kg)
1
045
13.0
1
045
14.0
1
045
15.7
1
045
17.5
1
045
18.5
1
045
22.0
1
045
23.5
1
045
4.29
1
045
4.29
1
045
5.20
1
045
5.20
1
045
4.08
1
045
10.4
1
045
2.54
Integral Incoming Meter Packs - 120mm² max cable
250A ct op. 3ph 4w Energy Meter Pack - Std
250A ct op. 3ph 4w Energy Meter Pack - MID
Contains: Digital meter offering Amps,Volts, kWh
readout plus pulsed output, ct's, fuses, & cable loom
(the latter supplied loose for connection by others)
Internal dia of ct's - 27.5mm
8GP1933-0DA11
8GP1933-0DA13
1
045
2.29
1
045
1.70
Integral Incoming Meter Packs - 185mm² max cable
250A ct op. 3ph 4w Energy Meter Pack - Std
250A ct op. 3ph 4w Energy Meter Pack - MID
Contains:Cable Spreader Box,digital meter offeringAmps,
Volts,kWh readout,plus pulsed output,ct's,fuses,& cable
loom (the latter supplied loose for connection by others)
Internal dia of ct's - 45mm
Dims:
245
430
155
8GP1933-0DA12
8GP1933-0DA14
1
045
1
045
Selection and ordering data
