Type
External Dimensions Order No
H x W x D (mm)
125A TPN rated Distribution Boards
4 way
490 430 155
6 way
570 430 155
8 way
650 430 155
12 way
815 430 155
16 way
895 430 155
20 way
1000 430 155
24 way
1140 430 155
8GP1 204-2DA54
8GP1 206-2DA54
8GP1 208-2DA54
8GP1 212-2DA54
8GP1 216-2DA54
8GP1 220-2DA54
8GP1 224-2DA54
Incomer Options & Kits for the above
100A DP Switch Disconnector *
100A TP Switch Disconnector
100A 4P Switch Disconnector **
125A DP Switch Disconnector *
125A TP Switch Disconnector
125A TP HFL Switch Disconnector**
125A 4P Switch Disconnector **
125A 4P HFL Switch Disconnector**
125A 4P 30mA rccb **
125A 4P 300mA rccb **
Direct Connection Kit - 50mm² cable
IncomingCableConnectionKit-120mm²cable
OutgoingDirectConnectionKit-50mm²cable
5TE1 201-0DA
5TE1 301-0DA
5TE1 401-0DA
5TE1 202-0DA
5TE1 302-0DA
5TT8 814
5TE1 402-0DA
5TT8 815
5SM3 345-0
5SM3 645-0
8GP1 854-0DA10
8GP1 856-0DA10
8GP1 855-0DA10
Conversion/Connection Kits
125A TP to SP Conversion Kit
4P rccb Connection Kit
8GP1 853-0DA20
8GP1 886-0DA10
Distribution Board expansion Unit ***
12wayAdd-on125ATP&NDistributionBoard
125AVertical Connection Kit (for the above)
8GP1 937-2DA50
8GP1 981-2DA10
125A TPN rated Distribution Boards with Integral DIN Rail
4 way
650 430 155
8 way
815 430 155
12 way
975 430 155
16 way
1140 430 155
20 way
1140 430 155
8GP1 104-2DA50
8GP1 108-2DA50
8GP1 112-2DA50
8GP1 116-2DA50
8GP1 120-2DA50
Features:
• Type Tested & ASTA certified to BS EN 60439-3
• 10kA for 0.1 second short circuit rating
• 16kA conditional short circuit rating
• Rated Voltage 230/400V 50/60Hz
• Integral meter ready facility
• Modular Construction
• 1mm Sheet Steel Enclosure
• Colour: Siemens light grey to RAL 7035
• Degree of Protection: IP3X
• Shrouded outgoing neutral terminals
• Top & Bottom entry via undrilled
removable gland plates
1.3
1
125A Type B Surface Mounting
Distribution Boards
ALPHA BS II
Selection and ordering data
Siemens IC LMV LV : 2012
*** For use with 125A 16,20 & 24 wayTP&N Distribution Boards only
* Requires 8GP1 853-0DA20 single phase connection kit
** Requires 8GP1 886-0DA10 4P connection kit
