KT5 5, 7KT5 6 time counters
for front-panel mounting
12/10
Siemens ET B1 · 10/2008
12
■
Overview
Time and pulse counters for control cabinets, control and
mechanical engineering are used, e.g. in boilers, machine tools
or compressors. The pulse counters count the starting frequencies.
This supports planning for preventative maintenance.
In-time and regular maintenance is the best protection against
unexpected shutdowns. Time counters count the time in hours
with an accuracy of two decimal places (hundredths of an hour).
■
Benefits
•
Time and pulse counters help to plan maintenance intervals
and ensure high plant availability.
■
Technical specifications
7
KT5 500 7KT5 501 7KT5 502 7KT5 503 7KT5 504 7KT5 505
Standards
DIN VDE 0435-110; EN 60255-6
Rated control supply voltage U
c
V AC
--
115
230
115
230
24
V DC 10 ... 80 --
Operating range
× U
c
0.9 ... 1.1
Rated frequency
Hz
--
50
60
50
Rated power dissipation P
v
VA
< 1
0.2
1.8
0.9
1.8
0.2
Method of operation
Counting of
Hours
Display
Drum-type register
h
00000.00
Pulse duration
Pulse length, pulse interval
ms
50
Front-panel mounting
Switchboard cutout
•
Without cover 55 mm × 55 mm
mm × mm 45.2 × 45.2
+0.3
•
With cover 55 mm × 55 mm
Ø mm 50.2
+0.3
Terminals
± screw (Phillips)
1
Conductor cross-sections
Rigid
mm
2
1.5
Flexible, with end sleeve, min.
mm
2
0.75
Permissible ambient temperature
°C
-10 ...
+70
Degree of protection
Acc. to EN 60529
•
Front panel
IP65
•
Installation with seal
IP43
•
Terminals
IP20, with connected conductors
Safety class
Acc. to EN 61140/ VDE 0140-1
II
Permissible humidity
%
< 93
7
KT5 600 7KT5 601 7KT5 602 7KT5 603 7KT5 604
Standards
DIN VDE 0435-110; EN 60255-6
Rated control supply voltage U
c
V AC
--
115
230
115
230
V DC 10 ... 50
--
Operating range
× U
c
0.9 ... 1.1
Rated frequency
Hz
--
50
60
Rated power dissipation P
v
VA
< 1
Method of operation
Counting of
Hours
Display
Drum-type register
h
00000.00
Pulse duration
Pulse length, pulse interval
ms
50
Front-panel mounting
Switchboard cutout
mm × mm 68
+0.5
× 68
+0.5
Terminals
± screw (Phillips)
1
Conductor cross-sections
Rigid
mm
2
1.5
Flexible, with end sleeve, min.
mm
2
0.75
Permissible ambient temperature
°C
-10 ...
+70
Degree of protection
Acc. to EN 60529
•
Front panel
IP52
•
Terminals
IP00
Safety class
Acc. to EN 61140/ VDE 0140-1
II
Permissible humidity
%
< 93
