KT5 8 time and pulse counters
12/9
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
12
■
Selection and ordering data
■
Dimensional drawings
■
Schematics
Terminals
■
More information
Time counters count the time in hours with an accuracy of two
decimal places (hundredths of an hour). The pulse counter sums
up the number of pulses, e.g. the making operations of devices.
A power supply is required at terminals 1 and 3 of the electronic
counters so that the device can constantly display the measured
values. Once terminal 3 is supplied with voltage (for DC "+"), the
counting procedure starts. If terminal 4 is supplied short-time
with voltage (for DC "+"), the counter is reset.
In the case of electronic counters, the counting result is saved
indefinitely in the event of a power failure (EEPROM). On recovery
of the power, the counting is continued from the saved value.
As well as a modern design, the electronic counter has a 7-digit
LCD, which can be reset electrically or manually.
U
c
Frequency MW DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
V
Hz
Unit(s) Unit(s) kg
Time counters
Mechanical counting mechanism,
display 00000.00 h without zero position
12 ... 24
DC --
2
A
7
KT5 801
027 1
1
0.095
24
AC
50
A
7
KT5 802
027 1
1
0.095
115
AC
B
7
KT5 803
027 1
1
0.095
230
AC
A
7
KT5 804
027 1
1
0.095
115
AC
60
B
7
KT5 806
027 1
1
0.095
230
AC
B
7
KT5 807
027 1
1
0.095
Pulse counters
Mechanical counting mechanism,
display 0000000
without zero position
12 ... 24
DC --
2
B
7
KT5 811
027 1
1
0.095
24
AC
50/60
B
7
KT5 812
027 1
1
0.095
230
AC
B
7
KT5 814
027 1
1
0.095
Electronic time counters
LCD 000000.0 h without zero position
12 ... 150
DC,
24 ... 240
AC
--
50/60
2
B
7
KT5 821
027 1
1
0.080
With electrical zero positioning
12 ... 150
DC,
24 ... 240
AC
--
50/60
B
7
KT5 822
027 1
1
0.080
With electrical and mechanical zero positioning
12 ... 150
DC,
24 ... 240
AC
--
50/60
B
7
KT5 823
027 1
1
0.080
Electronic pulse counters
LCD 0000000
With electrical and mechanical zero positioning
12 ... 150
DC,
24 ... 240
AC
--
50/60
2
B
7
KT5 833
027 1
1
0.080
7
KT5 80.
7
KT5 81.
7
KT5 82.
7
KT5 833
I2_11289a
2 3
36
1 2 3 4
36
44
64
6
45
7
KT5 801
7
KT5 802
7
KT5 803
7
KT5 804
7
KT5 806
7
KT5 807
7
KT5 811
7
KT5 812
7
KT5 814
7
KT5 821
7
KT5 822, 7KT5 823, 7KT5 833
3(-)
2(
+)
3(
N)
2(
L)
L1(+) N(–)
1 2 3 4
K1
I2_11616b
+/~ –/~
Count
L1(+) N(–)
1 2 3 4
K1 K2
I2_11288b
+/~ –/~
Count Reset
