Overview
Time and pulse counters are used for the reliable monitoring of
production and service times, which enables the exact planning
and monitoring of production sequences, maintenance cycles
and warranty times.
As well as the proven electromechanical time and pulse
counters for mounting in distribution boards, we also supply
digital time and pulse counters.
The fields of application for both counter types are very diverse,
such as the recording of operating hours of machines, systems or
building management systems, as well as pulse counting for
general volume flow counting, registration of starting frequencies,
starting cycles or production quantities in systems and machines.
■
Benefits
•
Time and pulse counters help to plan maintenance intervals
and ensure high plant availability
•
Versions without zero position and with electric or manual zero
position for all applications
•
Flexible application of the digital counters for power supplies
of 12 to 150 V DC and 24 to 240 V AC in a single device.
■
Technical specifications
7
KT5 801 7KT5 802 7KT5 803 7KT5 804 7KT5 806 7KT5 807
Standards
DIN VDE 0435-110; EN 60255-6; UL 863
Approved acc. to
UL 863, UL File No. E300537, CSA C22.2 No. 6 and 55
Rated control supply voltage U
c
V AC --
24
115
230
115
230
V DC 12 ... 24 --
Operating range
At 50/60 Hz
×
U
c
0.9 ... 1.1
Rated frequency
Hz
--
50
60
Rated power dissipation P
v
VA < 1
< 2
Method of operation
Counting of
Hours
Display
Drum-type register
h
00000.00
Terminals
± screw (Phillips)
1
Conductor cross-sections
Rigid
mm
2
1.5
Flexible, with end sleeve, min.
mm
2
0.75
Permissible ambient temperature
°C -10 ... +70
Degree of protection
Acc. to EN 60529
IP20, with connected conductors
Safety class
Acc. to EN 61140/VDE 0140-1
II
Permissible humidity
%
< 80
7
KT5 811 7KT5 812 7KT5 814 7KT5 821 7KT5 822 7KT5 823 7KT5 833
Standards
DIN VDE 0435-110; EN 60255-6; UL 863
Approved acc. to
UL 863, UL File No. E300537, CSA C22.2 No. 6 and 55
Rated control supply voltage U
c
V AC --
24
230
24 ... 240
V DC 12 ... 24 --
--
12 ... 150
Operating range
At 50/60 Hz
×
U
c
0.9 ... 1.1
Rated frequency
Hz
--
50/60
Rated power dissipation P
v
VA < 1
< 2
< 1
Method of operation
Counting of
Pulses
Hours
Pulses
Display
Drum-type register
0000000
--
--
LCD
h
--
000000.0
--
--
--
0000000
Counting frequency
Hz
10
--
10
Pulse duration
ms
50
--
50
Resetting
Electrical
--
Yes
Mechanical
--
Yes
Terminals
± screw (Phillips)
1
Conductor cross-sections
Rigid
mm
2
1.5
Flexible, with end sleeve, min.
mm
2
0.75
Permissible ambient temperature
°C -10 ... +70
Degree of protection
Acc. to EN 60529
IP20, with connected conductors
Safety class
Acc. to EN 61140/VDE 0140-1
II
Permissible humidity
%
< 80
