BETA Measuring
Single-Phase Measuring Devices
7
KT1 0 analog measuring devices
12/7
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
12
■
Overview
These devices for measuring voltages and currents can be used
for monitoring input and output currents or device currents in
electric plants. They are suitable for direct connection in a
single-phase system or for three-phase systems when used in
conjunction with a measuring selector switch.
■
Benefits
•
The 7KT1 020 ammeters can be equipped with changeable
scales for primary currents of 60, 150 or 400 A AC, depending
on the transformer ratio of the installed current transformer.
The changeable scales are included in delivery. This ensures
universal application
•
Permanent overload up to 20 % does not damage the device.
Protection for your plant.
■
Technical specifications
■
Selection and ordering data
■
Dimensional drawings
■
Schematics
Terminals
7
KT1 000
7
KT1 01.
7
KT1 020
Standards
EN 60051-2
Measuring ranges
•
Direct measurement
V AC 0 ... 500
--
--
A AC --
0 ... 25
--
A AC --
0 ... 40
--
A AC --
0 ... 60
--
•
Transformer measurement
A AC --
--
0 ... 150/5
Max. permissible measuring frequency
Hz
45 ... 65
Display
Pointer
Measuring accuracy
At 23
±
1
°C
%
±
1.5
±
3
±
1.5
Rated operational power P
s
VA < 2
< 1.1
Temperature influence
%/
°C
±
0.03
Overload capability
Continuous
1.2
× U
meas
1.2
×
I
meas
Short-time for 1 s
2
× U
meas
10
×
I
meas
Test voltage
50
Hz, 1 min
kV > 2
Terminals
± screw (Pozidriv)
1
2
1
Conductor cross-sections
Rigid, max.
mm
2
1
× 6/2 × 4
1
× 25/2 × 16
1
× 6/2 × 4
Flexible, with end sleeve, min.
mm
2
0.75
0.75
Permissible ambient temperature
°C -10 ... +55
Degree of protection
IP20, with connected conductors
U
meas
I
meas
MW DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
V AC A AC
Unit(s) Unit(s) kg
Analog voltmeters
500
4
B
7
KT1 000
027 1
1
0.105
Analog ammeters for direct connection
25
4
B
7
KT1 010
027 1
1
0.110
40
B
7
KT1 011
027 1
1
0.125
60
B
7
KT1 012
027 1
1
0.135
Analog ammeters for transformer connection
with 3 different interchangeable scales
0 ... 60
A,
0 ... 150
A and
0 ... 400
A
0 ... 60/5
0 ... 150/5
0 ... 400/5
4
B
7
KT1 020
027 1
1
0.105
7
KT1 000
7
KT1 01.,
7
KT1 020
45
86
I2_11611b
64
44 6
6 7
70
5 7
70
7
KT1 000
7
KT1 01.,
7
KT1 020
© Siemens AG 2008
