BETA Monitoring

Monitoring of Electrical Values

5

TT3 voltage relays

13/3

Siemens ET B1 · 10/2008

13

*

You can order this quantity or a multiple thereof.

Overview

Voltage relays are used for device and plant protection, supplying

emergency light devices and the detection of N-conductor

breaks and short-time voltage interruptions.

They are available as undervoltage, overvoltage and under/

overvoltage relays. The devices are equipped with different

functions, depending on their intended use, and comply with the

pertinent regulations.

Benefits

Complete voltage protection in a compact design for overvoltage

and undervoltage monitoring in a single device

Plants and devices are reliably and easily protected by

phase-failure relays

Overvoltages and consequential damage due to high voltages

are prevented through N-conductor monitoring

Asymmetry monitoring in the voltage relay also protects three-

phase AC motors against operation with voltage skew.

Technical specifications

5

TT3 400 5TT3 404 5TT3 406 5TT3 194 5TT3 195

5

TT3 401 5TT3 405

5

TT3 402

5

TT3 403

Standards

IEC 60255; DIN VDE 0435-110, -303

Rated control voltage U

c

V AC 230/400

400

Operating range (overload capability)

× U

c

1.1

1.35

Rated frequency

Hz

50/60

Response values

ON-switching

× U

c

0.9/0.95

4 %

hysteresis

OFF-switching

0.7/0.85

0.7 ... 0.95 0.9 ... 1.3

Minimum contact load

V; mA 10; 100

Phase asymmetry

Setting accuracy

% --

Approx.

5 ... 10

--

Approx.

5 ... 10

Repeat accuracy

% --

1

--

1

Phase failure detection

At L1 or L2 or L3

ms

100

--

N-conductor monitoring

--

Yes

--

Rated insulation voltage U

i

Between coil/contact

kV 4

Contacts

contact (AC-11)

A

4

Electrical isolation

Creepage distances and

clearances

Actuator/contact

mm 3

5.5

Rated impulse withstand voltage U

imp

Actuator/contact

kV > 2.5

> 4

Terminals

±

screw (Pozidriv)

1

Conductor cross-sections

Rigid, max.

mm

2

2

× 2.5

Flexible, with end sleeve, min.

mm

2

0.5

Permissible ambient temperature

°C -20 ... +60

Resistance to climate

Acc. to EN 60068-1

20/60/4
