BETA Measuring

Three-Phase Measuring Devices

7

KT1 1 E-counters instabus KNX

11/24

Siemens ET B1 · 10/2008

11

Technical specifications

1)

See table

on page 11/23.

7

KT1 162

7

KT1 165

Standards

Supply

Rated control voltage U

e

V AC 230

Operating range U

e

0.80 ... 1.20

Rated frequency

Hz

50

Operating frequency range

Hz

45 ... 65

Power consumption

Per phase

VA

0.8

Measuring inputs

Connection type

Direct

Transformer

Voltage

V

400

Operating range voltage

V

320 ... 480

Current

A

63

5

Operating range current

Direct connection

A

0.005 ... 63

--

Transformer connection

A

--

0.005 ... 6

Minimum operational current

mA

5

Current factor

Of transformer,

input in full digits

FAI

--

0 ... 255

Frequency

Hz

50

Operating frequency range

Distortion factor

3 %;

symmetric sinus curve

Hz

45 ... 65

Overload capability

Voltage

Duration: phase/N

V

276

1

second: phase/N

V

460

Duration: phase/phase

V

480

1

second: phase/phase

V

800

Current

Duration

A

76

6

1

second

A

126

10

Display

Rate

Double

LCD H × W

mm × mm 8 × 4

Readout data

See table on page 11/23.

7-

digit with decimal points

Active/reactive

Active energy

Drum-type register H × W:

mm × mm

7-

digit with 1 decimal

Display period

/

s

0.5

Storage of measured values

kWH EEPROM

Measuring accuracy

At 23 °C

±

1

°C

Active energy

Acc. to IEC 61036

Class

2

Safety

Supply measuring circuit isolation

Electrical

Rated insulation voltage

V

600

Rated impulse withstand voltage

Inputs against ground

for 1 min. at 50 Hz

kV

4

Overvoltage category

VDE 0110 T1

III

Pulse output

,

S0 interface

Acc. to

IEC 61393/DIN 43864

IR test output LED

Imp/Wh 10

Terminals, output

Imp/kWh 10

1

Minimum pulse duration ms

125

External voltage

V DC 5 ... 30

Current

mA

10 ... 20

Resistance

k

0.5 ... 1.5

instabus KNX interface

Standard

EIS 9

Readout data

1)

Terminals

Main current paths

±

screw (Pozidriv)

2

Supply/control terminals

Blade for slotted screw mm 0.4 × 2.5

Conductor cross-sections

Main current paths

Rigid (max.)

mm

2

1

× 10

Rigid (min.)

mm

2

1

× 1.5

Conductor cross-sections

Supply/control terminals

Rigid (max.)

mm

2

1

× 2.5

Flexible, with end sleeve mm

2

1

× 0.75
