BETA Measuring

Three-Phase Measuring Devices

7

KT1 2 current transformers

11/27

Siemens ET B1 · 10/2008

*

You can order this quantity or a multiple thereof.

11

Overview

This three-phase current transformer can be used in distribution

boards according to DIN 43880. The measuring leads are routed

vertically through the standard mounting rail.

This type of current transformer is suitable for supply systems or

outgoing conductors in connection with the installation of a 5TE8

switch or a 5TE1 disconnector, as the primary connecting leads

do not have to be interrupted.

The current transformer is designed for cables of up to 13 mm in

diameter, e.g. H07V-R with 50 mm

2

conductor cross-section.

Benefits

The current transformer has an accuracy class 1 in accordance

with EN 60044-1. This value is better than most measuring

devices in this area of application.

The versions designed for a transformer ratio of 60/5 A, 100/5 A

and 150/5 A enable an even broader range of applications.

Technical specifications

Selection and ordering data

Dimensional drawings

Schematics

Note:

Current transformers must not be operated with open terminals

as this can result in dangerously high voltages, which may result

in personal injuries and property damage. It also exposes the

transformer to thermal overload.

7

KT1 200

7

KT1 201

7

KT1 202

Standards

EN 60044-1

Secondary rated current strength

A

5

Accuracy class

Cl.

1

Rated power

VA 1.25

2.5

3.75

Rated frequency f

n

Hz

50/60

Thermal current limit

I

th

short-time

A

60

×

I

e

Thermal continuous current

A

1

×

I

e

Overcurrent limit factor

FS 5

Rated impulse withstand voltage U

imp

kV > 3

Creepage distances and clearances

mm > 3

Rated operational voltage U

e

V AC 720

Rated operational current

I

e

A AC 3 × 60

3

× 100

3

× 150

Terminals

±

screw (Pozidriv)

PZ 1

Conductor cross-sections

-

Rigid

mm

2

0.5 ... 4

-

Flexible, with end sleeve

mm

2

0.5 ... 2.5

Permissible ambient temperature

°C -5 ... +60

Resistance to climate

Acc. to EN 60068-1

20/60/4

U

e

I

e

I

sec

MW DT Order No.

Price

per PU

PG PU PS*/

P. unit

Weight

per PU

approx.

V AC A AC V DC

Unit(s) Unit(s) kg

Current transformers

720

3

× 60

5

6

B

7

KT1 200

027 1

1

0.460

3

× 100

B

7

KT1 201

027 1

1

0.460

3

× 150

B

7

KT1 202

027 1

1

0.465

7

KT1 200

7

KT1 201

7

KT1 202

105

45

90

I2_07809a

7

64

44

24

K/P

1

K/P

1

K/P

1

L/P

2

l k l k l

L/P

2

L/P

2

k

64

7

KT1 200

7

KT1 201

7

KT1 202

© Siemens AG 2008
