441 / 582
BETA Measuring
Three-Phase Measuring Devices
7
KT1 1 E-counters instabus KNX
11/25
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
11
■
Selection and ordering data
■
Dimensional drawings
E-counters
7
KT1 162
7
KT1 165
Ambient conditions
Temperature
Storage
°C
-40 ...
+70
Operation
°C
0 ...
+55
Relative air humidity
Storage
%
98
Operation
%
80
Minimum vibration
Sinus amplitude at 50 Hz
mm
±
0.25
Degree of pollution
VDE 0110-1
2
Degree of protection
(
terminal area)
IP40 (IP20)
I
e
U
c
MW DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
A AC
V DC
Unit(s) Unit(s) kg
E-counters for 3/4 wire connection,
with LCD,
with IR interface for double rate
Direct connection,
with 2 S0 pulse outputs
and instabus interface
Active and reactive energy
10 (63)
3
× 230/400 6 B
7
KT1 162
027 1
1
0.450
Transformer connection,
with 2 S0 pulse outputs
and instabus KNX interface
Active and reactive energy
Trans-
formers /5(6)
3
× 230/400 6 B
7
KT1 165
027 1
1
0.390
IR measuring heads for 7KT1 16
C
7
KT9 030
027 1
1
0.170
For reading out data according to IEC 61107,
with 9-pin COM connector and readout software
7
KT1 162
7
KT1 165
