8US 60 mm Busbar Systems
UL applications
10/27 Siemens LV 10 · 2014
8US1923-3UA01 End and intermediate holders for flat
copper profiles
100 500 480 30x5 500 J or T 800
8US1923-3UA01 100 500 600 30x5 500 J or T 800
8US1923-3UA01 100 500 480 30x5 400 RK1 800
8US1923-3UA01 100 500 600 30x5 400 RK1 800
8US1923-3UA01 25 756 600 30x10 -- -- 250
8US1923-3UA01 22 756 600 30x10 -- -- 400
8US1923-3UA01 65 756 480 30x10 400 3VL-UL; 3RV.7; 3RV.8 800
8US1923-3UA01 35 756 600 30x10 400 3VL-UL; 3RV.7; 3RV.8 800
8US1923-3UA01 50 756 480 30x10 600 3VL-UL; 3RV.7; 3RV.8 800
8US1923-3UA01 25 756 600 30x10 600 3VL-UL; 3RV.7; 3RV.8 800
8US1923-3UA01 100 756 480 30x10 600 J or T 800
8US1923-3UA01 100 756 600 30x10 450 J or T 800
8US1923-3UA01 100 756 480 30x10 400 RK1 800
8US1923-3UA01 100 756 600 30x10 400 RK1 800
8US1923-3UA01 65 -- 480 -- 400 3VL-UL; 3RV.7; 3RV.8 800
8US1923-3UA01 50 -- 480 -- 600 3VL-UL; 3RV.7; 3RV.8 800
8US1923-3UA01 35 -- 600 -- 600 3VL-UL; 3RV.7; 3RV.8 800
8US1923-3UA01 100 -- 480 -- 600 J or T 800
8US1923-3UA01 100 -- 600 -- 500 J or T 800
8US1923-3UA01 100 -- 480 -- 400 RK1 800
8US1923-3UA01 100 -- 600 -- 400 RK1 800
8US1213-4AH00 Device adapters for 3VL UL molded-case
circuit breakers
65 630 480 -- 600 -- 400
8US1213-4AH00 50 630 600 -- 600 -- 400
8US1213-4AH00 65 630 480 -- 400 3VL-UL; 3RV.7; 3RV.8 800
8US1213-4AH00 35 630 600 -- 400 3VL-UL; 3RV.7; 3RV.8 800
8US1213-4AH00 50 630 480 -- 600 3VL-UL; 3RV.7; 3RV.8 800
8US1213-4AH00 25 630 600 -- 600 3VL-UL; 3RV.7; 3RV.8 800
8US1211-4TR00 Busbar adapter 45 mm/ 72 mm 10 80 600 -- -- -- 400
8US1213-4AQ01 Busbar adapters for 3VL UL molded-
case circuit breakers
65 250 480 -- 250 -- 400
8US1213-4AQ01 50 250 600 -- 250 -- 400
8US1213-4AQ01 65 250 480 -- 250 3VL-UL; 3RV.7; 3RV.8 800
8US1213-4AQ01 25 250 600 -- 250 3VL-UL; 3RV.7; 3RV.8 800
8US1948-2AA00 Flat copper profiles 103 1400 600 -- 1600 Class L N/A
8US1943-3AA00 Busbar supports, 3-pole, double-T profile 30 1200 600 -- -- -- 400
8US1943-3AA00 25 1200 600 -- -- -- 700
8US1943-3AA00 65 1200 480 -- 800 3VL-UL; 3RV.7; 3RV.8 800
8US1943-3AA00 30 1200 600 -- 800 3VL-UL; 3RV.7; 3RV.8 800
8US1943-3AA00 100 1200 480 -- 800 Class T 800
8US1943-3AA00 100 1200 600 -- 600 J or T 800
8US1943-3AA00 100 1200 480 -- 600 Class RK1 800
8US1943-3AA00 100 1200 600 -- 400 Class RK1 800
8US1943-3AA00 30 1400 600 -- -- -- 400
8US1943-3AA00 25 1400 600 -- -- -- 700
8US1943-3AA00 65 1400 480 -- 800 3VL-UL; 3RV.7; 3RV.8 800
8US1943-3AA00 30 1400 600 -- 800 3VL-UL; 3RV.7; 3RV.8 800
8US1943-3AA00 100 1400 480 -- 800 T 800
8US1943-3AA00 100 1400 600 -- 600 J or T 800
8US1943-3AA00 100 1400 480 -- 600 RK1 800
8US1943-3AA00 100 1400 600 -- 400 RK1 800
8US1943-3AA00 65 -- 480 -- 800 3VL-UL; 3RV.7; 3RV.8 800
8US1943-3AA00 30 -- 600 -- 800 3VL-UL; 3RV.7; 3RV.8 800
8US1943-3AA00 100 -- 480 -- 800 T 800
8US1943-3AA00 100 -- 600 -- 600 J or T 800
8US1943-3AA00 100 -- 480 -- 600 RK1 800
8US1943-3AA00 100 -- 600 -- 400 RK1 800
8US1922-1GC00 Covers for connection terminal set -- -- -- -- -- -- --
Components used Short-
circuit
current
rating
(SCCR)
Total
Ambient conditions
Article No. Description Max.
rated
current Ie
Rated
voltage Ue
Busbar
dimen-
sions
Rated current
of the fuse
used Ie
Fuse type used Max. spac-
ing of busbar
supports
kA A V A mm
