8US 60 mm Busbar Systems

Busbar device adapters and device holders

from 630 A to 1 600 A

10/23

Siemens LV 10 · 2014

* You can order this quantity or a multiple thereof.

For universal device design

Number

of sup-

port rails

(35 mm)

Adapter

Connecting cable

Stan-

dard

DT Article No.

Price

per

(UNIT,

SET,

PS*/

P. unit

PG Weight

per PU

approx.

Length Width Cross-

sec-

tion

Tem-

pera-

ture

max.

Length Rated

current

Rated

voltage

mm mm AWG °C mm A

Devices 45 mm wide

Device holder for side mounting onto busbar

device adapter, no electrical contact

8US1250-1AA10

200 45 --

UL 508

}

8US1250-1AA10

1 1 unit 143 0.278

8US1250-5AS10

200 45 --

UL 508

}

8US1250-5AS10

1 1 unit 143 0.234

8US1250-5AT10

260 45 --

UL 508

}

8US1250-5AT10

1 1 unit 143 0.264

8US1251-5DS10

8US1211-4TR00

Devices 45 mm and 72 mm wide

Busbar device adapter with connecting cables for contact with

busbars, welded connecting cable resistant up to 150 °C

200 45 12 150 165 25

690 UL 508

}

8US1251-5DS11

1 1 unit 143 0.314

200 45 12 150 99 25

690 UL 508

}

8US1251-5DS10

1 1 unit 143 0.290

260 45 12 150 99 25

690

}

8US1251-5DT10

1 1 unit 143 0.324

260 45 12 150 165 25

690 UL 508

}

8US1251-5DT11

1 1 unit 143 0.324

260 45 10 150 99 32

690 UL 508

}

8US1251-5NT10

1 1 unit 143 0.287

260 45 10 150 165 32

690 UL 508

}

8US1251-5NT11

1 1 unit 143 0.345

200 45 10 105 118 32

690 UL 508

}

8US1211-1NS10

1 1 unit 143 0.300

215 72 4

105 210 100 690 UR,

CSA

8US1211-4TR00

1 1 unit 143 0.623

8US1998-2BJ10

Lateral modules

For extending busbar device adapters

and device holders

of the same length

200 9 --

8US1998-2BJ10

1 10 units 143 0.021
