Busbar Systems
8US 60 mm Busbar Systems
Connector for 3NP1 fuse switch disconnectors
10/25
Siemens LV 10 · 2014
* You can order this quantity or a multiple thereof.
■
Selection and ordering data
For snap connections to 60 mm busbar systems
Rated current
I
u
LV HRC fuse links according to
IEC 60269-1
DT Article No.
Price
per PU
PU
(UNIT,
SET, M)
PS*/
P. unit
PG Weight
per PU
approx.
A
Size
kg
For cover level 32 / 70 mm,
with reach-around protection for 8US busbar system
Basic units
3NP1133-1BC20
Flat terminals
160
00 / 000
3NP1133-1BC10
1 1 unit
143 1.155
250
1 and 0
3NP1143-1BC10
1 1 unit
143 3.245
400
2 and 1
3NP1153-1BC10
1 1 unit
143 4.314
630
3 and 2
3NP1163-1BC10
1 1 unit
143 5.260
Box terminals
160
000
3NP1123-1BC20
1 1 unit
143 0.971
160
00 / 000
3NP1133-1BC20
1 1 unit
143 1.146
250
1 and 0
3NP1143-1BC20
1 1 unit
143 3.306
400
2 and 1
3NP1153-1BC20
1 1 unit
143 4.672
630
3 and 2
3NP1163-1BC20
1 1 unit
143 5.538
With MFM electromechanical fuse monitoring
3NP1133-1BC21
Flat terminals
160
00 / 000
3NP1133-1BC11
1 1 unit
143 1.698
250
1 and 0
3NP1143-1BC11
1 1 unit
143 3.914
400
2 and 1
3NP1153-1BC11
1 1 unit
143 5.016
630
3 and 2
3NP1163-1BC11
1 1 unit
143 5.910
Box terminals
160
00 / 000
3NP1133-1BC21
1 1 unit
143 1.702
250
1 and 0
3NP1143-1BC21
1 1 unit
143 3.993
400
2 and 1
3NP1153-1BC21
1 1 unit
143 5.500
630
3 and 2
3NP1163-1BC21
1 1 unit
143 6.223
With EFM 10 electronic fuse monitoring
3NP1133-1BC22
Flat terminals
160
00 / 000
3NP1133-1BC12
1 1 unit
143 1.394
250
1 and 0
3NP1143-1BC12
1 1 unit
143 3.564
400
2 and 1
3NP1153-1BC12
1 1 unit
143 4.666
630
3 and 2
3NP1163-1BC12
1 1 unit
143 5.555
Box terminals
160
000
3NP1123-1BC22
1 1 unit
143 1.109
160
00 / 000
3NP1133-1BC22
1 1 unit
143 1.406
250
1 and 0
3NP1143-1BC22
1 1 unit
143 3.650
400
2 and 1
3NP1153-1BC22
1 1 unit
143 5.014
630
3 and 2
3NP1163-1BC22
1 1 unit
143 5.826
With EFM 20 electronic fuse monitoring and
line monitoring
3NP1133-1BC23
Flat terminals
160
00 / 000
3NP1133-1BC13
1 1 unit
143 1.411
250
1 and 0
3NP1143-1BC13
1 1 unit
143 3.641
400
2 and 1
3NP1153-1BC13
1 1 unit
143 4.750
630
3 and 2
3NP1163-1BC13
1 1 unit
143 5.611
Box terminals
160
000
3NP1123-1BC23
1 1 unit
143 1.121
160
00 / 000
3NP1133-1BC23
1 1 unit
143 1.470
250
1 and 0
3NP1143-1BC23
1 1 unit
143 3.685
400
2 and 1
3NP1153-1BC23
1 1 unit
143 5.090
630
3 and 2
3NP1163-1BC23
1 1 unit
143 5.920
Accessories
Connection modules
For 32-mm cover level with
box terminal 6 mm ... 70 mm
2
3NP1933-1BC00
1 1 unit
143 0.193
