CI insulated distribution boards

Corner enclosures

2010

CA08103002Z-EN

Prepared enclosures

PreparedenclosuresCornerenclosures

Rated

operational

current

Part no.

Article no.

Price

See price

list

Std. pack

Notes

I

e

A

Corner enclosures

•

Protection type IP65

•

Up to 5-pole and up to 1000 A

• 3

pole 1600 A

•

For 1600 A busbars additional enclosure for PE/N bars

Design "In the corner"

1)

•

Connection material

(

transport split)

•

Busbars pre-bent

•

Non-transparent cover

250

400

630

ESKI630-310/I44

002144

1

off

For main conductor L1, L2, L3

For protective or neutral

conductor PE, PEN

ESKI630-320/I44

002169

For main conductor L1, L2, L3

For protective or neutral

conductor PE, N

1000

ESKI1000-310/I44

002171

For main conductor L1, L2, L3

For protective or neutral

conductor PE, PEN

ESKI1000-320/I44

002170

For main conductor L1, L2, L3

For protective or neutral

conductor PE, N

1600

ESKI1600-300/I44

002172

For main conductor L1, L2, L3

1000

EPENI1000-010/I44

002173

For protective or neutral

conductor PE, PEN

EPENI1000-020/I44

002174

For protective or neutral

conductor PE, N

1600

EPENI1600-010/I44

002176

For protective or neutral

conductor PE, PEN

EPENI1600-020/I44

002175

For protective or neutral

conductor PE, N

Design "Around the

corner"

2)

•

Connection material

(

transport split)

•

Busbars pre-bent

•

Transparent cover

250

400

630

ESKU630-310/I44

002178

For main conductor L1, L2, L3

For protective or neutral

conductor PE, PEN

ESKU630-320/I44

002179

For main conductor L1, L2, L3

For protective or neutral

conductor PE, N

1000

ESKU1000-310/I44

002181

For main conductor L1, L2, L3

For protective or neutral

conductor PE, PEN

ESKU1000-320/I44

002180

For main conductor L1, L2, L3

For protective or neutral

conductor PE, N

1600

ESKU1600-300/I44

002182

For main conductor L1, L2, L3

1000

EPENU1000-010/I44

002183

For protective or neutral

conductor PE, PEN

EPENU1000-020/I44

002184

For protective or neutral

conductor PE, N

1600

EPENU1600-010/I44

002186

For protective or neutral

conductor PE, PEN

EPENU1600-020/I44

002185

For protective or neutral

conductor PE, N

Notes

1)

2)

ESKI..., EPENI..., ESKU..., EPENU...

HPL20048EN
