CI insulated enclosures
Panel enclosures for fuses
2010
CA08103002Z-EN
www.eaton.comEnclosures with components fitted
Enclosureswithcomponents fittedPanelenclosures for fuses
Dimensions
Enclosure
depth
Rated
operational
current
Rated
operating
voltage
Max. fuse-
link
Fused
circuits
Part no.
Article no.
Price
See price
list
Std. pack
I
e
U
e
mm
mm
A
V AC
A
Number
Panel enclosures for fuses
•
Sides closed, but with full area knockout, open top and bottom
•
Protection type IP65
•
With 3-pole busbar mounting fuse base on busbars, replaceable from front
•
Transparent cover with quick-release fasteners
•
Protective shroud with inscription label
•
Sealable cover fasteners
150
25
500
25
A DII/E27 9 x 1-pole
3
x 3 pole
RS27/I23-125
074056
1
off
175
25
500
25
A DII/E27 9 x 1-pole
3
x 3 pole
RS27/I23-150
005240
150
63
400
35
A D02/E18 6 x 1-pole
4
x 3 pole
RS18/I23-125
081175
175
63
400
35
A D02/E18 6 x 1-pole
4
x 3 pole
RS18/I23-150
007613
150
63
690
35
A DIII/E33 2 x 3 pole
RS33/I23-125
083548
175
63
690
35
A DIII/E33 2 x 3 pole
RS33/I23-150
014732
Notes
Accessories for fuse enclosures ￫Page 20/46
Fuses, fuse adapters and screw-on cap
￫Chapter 19: Circuit-breakers, fuses
250
187.5
250
187.5
250
187.5
RS...I...
