Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

54 / 140

20/50 CI insulated enclosures
Individual enclosures without/with door in cover
2010 CA08103002Z-EN
Enclosures with components fitted
Enclosureswithcomponents fittedIndividualenclosureswithout/withdoor incover
Dimensions Rated
operational
current
Rated
operating
voltage
Max.
fuse-
link
Fused
circuits
PE and N terminals
Number x Cross-section
Part no.
Article
no.
Price
See
price list
Std.
pack
Notes
Ie U e
mm A V AC A Number mm2
Individual fuse enclosures (RS...E: cover without opening, RS...T: cover with door)
• Metric cable entry knockouts in all sides
• Protection type IP65
• With 3-pole busbar mounting fuse base on busbars, replaceable from front
• Transparent cover with quick-release fasteners
• PE/N bars, protective shroud with inscription label
• Fixing straps for wall fixing
• Cover fasteners can be sealed, enclosure depth 150 mm
25 500 25, DII/
E27
9 x 1-pole
3 x 3 pole
On each 2 x (6 - 35)
On each 9 x (1 - 6)
RS27/
I23E
013156
1 off
25, DII/
E27
9 x 1-pole
3 x 3 pole
On each 2 x (6 - 35)
On each 9 x (1 - 6)
RS27/
I23E/T
015529
63 400 35, D02/
E18
6 x 1-pole
4 x 3 pole
On each 2 x (6 - 35)
On each 6 x (4 - 25)
RS18/
I23E
020275
35, D02/
E18
6 x 1-pole
4 x 3 pole
On each 2 x (6 - 35)
On each 6 x (4 - 25)
RS18/
I23E/T
017902
63 690 35, DIII/
E33
2 x 3 pole On each 2 x (6 - 35)
On each 2 x (4 - 25)
RS33/
I23E
022648
35, DIII/
E33
2 x 3 pole On each 2 x (6 - 35)
On each 2 x (4 - 25)
RS33/
I23E/T
025021
25 500 25, DII/
E27
18 x 1-pole
6 x 3 pole
On each 2 x (6 - 35)
On each 18 x (1 - 6)
RS27/
I43E
029767
25, DII/
E27
18 x 1-pole
6 x 3 pole
On each 2 x (6 - 35)
On each 18 x (1 - 6)
RS27/
I43E/T
027394
63 400 35, D02/
E18
12 x 1-pole
8 x 3 pole
On each 2 x (6 - 35)
On each 12 x (4 - 25)
RS18/
I43E
032140
35, D02/
E18
12 x 1-pole
8 x 3 pole
On each 2 x (6 - 35)
On each 12 x (4 - 25)
RS18/
I43E/T
034513
A
A
250
187,5
B B
A
1 x M32/20
6 x M20
2 x M16
B
2 x M32/20
4 x M25/16
4 x M20
4 x M16
A
A
250
187,5
B B
A
A
250
187,5
B B
C
2 x M50/20
6 x M25/16
8 x M20
D
1 x M50/32
6 x M25/16
D
C
250
C
D
375
RS...I...E, RS...I...E/T HPL20050EN
