Terminals
2010 CA08103002Z-EN
Terminals 160 - 1000 A
Includes labels for terminal marking U, V, W - X, Y, Z - L 1, L 2, L3 - T 1, T 2, T 3 - PE, N, PEN, 
Ui = 1000 V AC
Assignment of rated current ￫Terminal capacities to IEC/EN 60439,
VDE 0660 Part 500 or EN 50021
Outer terminal for round or sectoral conductor, other side for copper strip.
Conversion kits for converting flat strip terminal to cable terminal ￫Page 16/69, terminal shroud￫Page 16/69
800 1 2 x 120 - 240
3 x 50 - 185
2 x 150 - 185
3 x 95 - 150
2 x (11 x 21 x 1) 50 x 20 K3X185/1
062985
1 off
3 K3X185/3
065358
4 K3X185/4
067731
5 K3X185/5
070104
1000 1 2 x 150 - 300
3 x 50 - 240
2 x 150 - 240
3 x 150 - 185
2 x 150 - 240
3 x 150 - 185
60 x 15 K3X240/1
060612
1 off
3 K3X240/3
058239
4 K3X240/4
055866
5 K3X240/5
053493
1 2 x 150 - 300
4 x 50 - 185
2 x 240
4 x 120 - 150
2 x 240
4 x 120 - 150
K4X185/1
079596
3 K4X185/3
077223
4 K4X185/4
074850
5 K4X185/5
072477
Notes 1) Copper strip
▃Copper bar
○ Round conductor, solid
 Round conductor, stranded
 Sectoral conductor, solid
 Sectoral conductor, stranded
Rated opera-
tional current
Poles Terminal capacities1) Terminal capacities1) Part no.
Article no.
Price
See price
list
Std. pack
Ie Cu ○
Al ○
Al  Copperstrip ▃Copper bar
A mm mm
KP HPL16068EN
