16/70 Accessories for control panel building
Single terminals, ultra-flat busbar terminals
2010 CA08103002Z-EN
www.eaton.comSingle terminals,ultra-flatbusbar terminals
Circuit
Rated uninterrupted
current
Terminal capacities
1)
Part no.
Article no.
Price
See price
list
Std. pack
I
u
Terminal capacities
for round conductors
Terminal capacities
for flat conductors
A
mm
2
mm
Insulated individual terminals 32 - 100 A
• With adhesive labels
• Can be screwed onto mounting plates and stacking mandrels of enclosures CI and CI‐K
• For snap-fitting to mounting rails to IEC/EN 60715
• Terminal capacities to IEC/EN 60947-1, VDE 0609 Part 1
• Rated insulation voltage U
i
= 1000 V AC
With two connections
32
○ 1.5 - 10
1.5 - 6
–
K10/1
093827
10 off
63
○ 4 - 16
16 - 25
6 - 16
–
K25/1
096200
10 off
100
○ 10 - 16
16 - 50
10 - 35
3 x 9 x 0.8
K50/1
098573
10 off
Notes
1)
⊙ Solid
Stranded
Flexible with ferrule
Copper strip
For use with
busbars
Terminal
capacities for
flat conductors
Rated operational
current,
flat conductor
Terminal capacities,
round conductors
Type:
○ solid
flexible with
ferrule
Part no.
Article no.
Price
See price
list
Std. pack
I
e
mm
mm
A
mm
2
Ultra-flat busbar terminals 100 - 800 A
Cu 12 x 5
3 x 9 x 0.8
6 x 9 x 0.8
4 x 16 x 0.8
6 x 16 x 0.8
100
160
200
250
○ 1.5 - 10
1.5 - 6
K12X5/25
002324
10 off
Cu 20 x 5
3 x 9 x 0.8
6 x 9 x 0.8
4 x 16 x 0.8
6 x 16 x 0.8
100
160
200
250
○ 1.5 - 10
1.5 - 6
K20X5/25
002327
10 off
Cu 20 x 5
Cu 20 x 10
3 x 9 x 0.8
6 x 9 x 0.8
4 x 16 x 0.8
6 x 16 x 0.8
10 x 16 x 0.8
100
160
200
250
400
○ 1.5 - 10
1.5 - 6
K20X10/35
002325
10 off
Cu 20 x 5
Cu 20 x 10
3 x 9 x 0.8
6 x 9 x 0.8
4 x 16 x 0.8
6 x 16 x 0.8
10 x 16 x 0.8
100
160
200
250
400
○ 1.5 - 10
1.5 - 6
K20X15/40
002285
10 off
Cu 20 x 10
Cu 20 x 15
3 x 9 x 0.8
6 x 9 x 0.8
4 x 16 x 0.8
6 x 16 x 0.8
10 x 16 x 0.8
11 x 21 x 1
100
160
200
250
400
630
○ 1.5 - 10
1.5 - 6
Cu 20 x 15
11 x 21 x 1
2 x (11 x 21 x 1)
630
800
○ 1.5 - 10
1.5 - 6
K20X15/50
002326
5 off
