Power factor meters, voltmeters
2010 CA08103002Z-EN
Power factormeters, voltmeters
Measuring
range
Measuring
range
Part no.
Article no.
Price
See price
list
Std. pack
A V
Power factor (p. f.) meters
• Rated operational voltage 3 × 400 V AC
• Current through transformer secondary winding 5 A/VA
• Scale division 0.5 capacitive - 1 - 0.5 inductive
0 - 10/20 – LWQ96
086856
1 off
Voltmeters, class 1.5
• To DIN 43780 and VDE 410
• Enclosure to DIN 43700
• Narrow version to DIN 43718
• Quadrant scale DIN 43802 (dual scale)
• Terminals protected against accidental contact
• Vertical operating position
• Snap fitting for EQ72 and EQ96
• Class 1.5
• Direct connection
Unshielded
EQ45
• 45 x 45 mm
– 0 - 250 EQ45C-250V
057968
1 off
– 0 - 500 EQ45C-500V
060341
1 off
EQ72
• 72 x 72 mm
– 0 - 250 EQ72-250V
033051
1 off
– 0 - 500 EQ72-500V
033052
– 0 - 600 EQ72-600V
033053
– 0 - 800 EQ72-800V
033054
EQ96
• 96 x 96 mm
– 0 - 250 EQ96-250V
033047
1 off
– 0 - 500 EQ96-500V
033048
– 0 - 600 EQ96-600V
033049
– 0 - 800 EQ96-800V
033050
Shielded 4 mT
EQ72
• 72 x 72 mm
– 0 - 250 EQ72S-250V
038581
1 off
– 0 - 500 EQ72S-500V
045700
4 off
– 0 - 600 EQ72S-600V
052819
1 off
EQ96
• 96 x 96 mm
– 0 - 250 EQ96S-250V
071803
1 off
– 0 - 500 EQ96S-500V
078922
4 off
– 0 - 600 EQ96S-600V
086041
1 off
– 0 - 800 EQ96S-800V
088414
1 off
0
300 600
0
300 600
0
300
600
0
300 600
0
300
600
EQ HPL16074EN
