Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

76 / 543

16/72 Accessories for control panel building
Copper strip, insulated
2010 CA08103002Z-EN
Copperstrip, insulated
Rated
operational
current1)
Dimensions
(number of layers
× width × layer
thickness)
Cross-
section2) Cu factor3) Color Part no.
Article no.
Price
See price
list
Std. pack
Ie
A mm mm 2
Copper strip insulated
• Laminated E‐Cu conductor, tin-plated
• Rated operating voltage 690 V AC
• UL approved up to 600 V AC
• Dielectric strength 20 kV/mm
• Insulating material heat resistant up to +105 °C
• Self-extinguishing to UL 94 V 0
• 2000 mm long, black (BK), blue (BU) and green/yellow (GNYE).
100 3 x 9 x 0.8 21.6 0.41 Black CU-BAND3X9X0.8-BK
081167
20 off
100 3 x 9 x 0.8 21.6 0.41 Yellow/green CU-BAND3X9X0.8-GNYE
081006
20 off
100 3 x 9 x 0.8 21.6 0.41 Blue CU-BAND3X9X0.8-BU
080960
20 off
160 6 x 9 x 0.8 43.2 0.83 Black CU-BAND6X9X0.8-BK
081414
10 off
160 6 x 9 x 0.8 43.2 0.83 Yellow/green CU-BAND6X9X0.8-GNYE
081367
10 off
160 6 x 9 x 0.8 43.2 0.83 Blue CU-BAND6X9X0.8-BU
081344
10 off
200 9 x 9 x 0.8 64.8 1.24 Black CU-BAND9X9X0.8-BK
081515
10 off
200 9 x 9 x 0.8 64.8 1.24 Yellow/green CU-BAND9X9X0.8-GNYE
081485
10 off
200 9 x 9 x 0.8 64.8 1.24 Blue CU-BAND9X9X0.8-BU
081436
10 off
250 6 x 16 x 0.8 74.4 1.43 Black CU-BAND6X16X0.8-BK
081310
10 off
250 6 x 16 x 0.8 74.4 1.43 Yellow/green CU-BAND6X16X0.8-GNYE
081275
10 off
250 6 x 16 x 0.8 74.4 1.43 Blue CU-BAND6X16X0.8-BU
081222
10 off
400 5 x 24 x 1 120 2.14 Black CU-BAND5X24X1-BK
119032
5 off
400 10 x 16 x 0.8 124 2.38 Black CU-BAND10X16X0,8-BK
080739
5 off
400 10 x 16 x 0.8 124 2.38 Yellow/green CU-BAND10X16X0,8-GNYE
080698
5 off
400 10 x 16 x 0.8 124 2.38 Blue CU-BAND10X16X0,8-BU
079736
5 off
630 5 x 32 x 1 160 2.85 Black CU-BAND5X32X1-BK
119035
5 off
630 8 x 24 x 1 192 3.42 Black CU-BAND8X24X1-BK
119033
5 off
630 10 x 24 x 1 240 4.28 Black CU-BAND10X24X1-BK
119034
5 off
630 11 x 21 x 1 231 4.44 Black CU-BAND11X21X1-BK
080923
5 off
630 11 x 21 x 1 231 4.44 Yellow/green CU-BAND11X21X1-GNYE
080836
5 off
630 11 x 21 x 1 231 4.44 Blue CU-BAND11X21X1-BU
080769
5 off
800 10 x 32 x 1 320 5.70 Black CU-BAND10X32X1-BK
119036
3 off
1000 10 x 40 x 1 400 7.12 Black CU-BAND10X40X1-BK
119037
3 off
1250 10 x 50 x 1 500 8.90 Black CU-BAND10X50X1-BK
119038
2 off
1600 10 x 80 x 1 800 14.25 Black CU-BAND10X80X1-BK
119039
1 off
Notes 1) Rated operational current: conforms to VDE 0281
2) Observe component wiring instructions
(e.g. min. terminal capacities in mm2)
3) Calculation of material surcharge￫Page 23/3
Information relevant for export to North America
Product Standards UL 758; EN 60439-1, -3; CE marking
UL File No. E248096
UL CCN AVLV2
CSA File No. UL report applies to both US and Canada
CSA Class No. –
NA Certification UL Listed, certified by UL for use in Canada
Conditions of Acceptability max. 105 ºC
Suitable for Appliance Wiring Material - Component
Max. Voltage Rating 600 V AC, 750 V DC
Copper strip HPL16072EN
