Accessories for control panel building
Cable screw glands
2010 CA08103002Z-EN
www.eaton.com16/63
Cable screwglands
Cable entry
External diameter of cable For use with NYM/NYY cables,
4-core
Part no.
Article no.
Price
See price
list
Std. pack
mm
mm
2
Multiple gaskets for cable glands V-M... , metric
M25
4 x 5 - 6
H03VV-F2 x 0.75/3 x 0.75 mm
2
MFD25
215451
50 off
M32
4 x 3.5 - 7
H03VV-F4 x 0.75 mm
2
MFD32
215452
25 off
Stoppers for unused openings in multiple gaskets MFD...
M25
6
–
MFV25-6
215453
50 off
M32
7
–
MFV32-7
215454
50 off
Part no.
Article no.
Price
See price
list
Std. pack
Information relevant for export to North America
PG cable glands
• Conduit union and lock nut with
grouding screw
• Suitable for standard commercial
conduit
• Suitable for all enclosures CI…-NA
￫Page 20/9
½ "
STB1/2ZOLL
045878
1 off
Product Standards
UL 467; UL 514B; CSA-C22.2 No. 18
UL File No.
E23018, E3060
UL CCN
DWTT, KDER
CSA File No.
LR 2884
CSA Class No.
4412-03, 4414-04
NA Certification
UL Listed, CSA certified
Conditions of Acceptability Only used in combination with CI-…-NA enclosures
Specially designed for NA Yes
Suitable for
Conduit, Tubing, and Cable Fittings, Grounding and
Bonding Equipment
Degree of Protection
Refer to main component information
See also
Refer to basic component information
¾ "
STB3/4ZOLL
060116
1 "
STB1ZOLL
052997
1 ¼ "
STB1-1/4ZOLL
043505
1 ½ "
STB1-1/2ZOLL
041132
2 "
STB2ZOLL
002203
Cable entry
Drilling
dimensions
External
diameter of cable
For use with NYM/NYY cables,
4-core
Part no.
Article no.
Price
See price
list
Std. pack
mm
mm
mm
2
Ventilation cable glands
• Color RAL 7035
Ventilation cable gland IP69
M20
20.5
6 - 13
H05VV-F 4 x 2.5/3 x 4 mm
2
,
NYM 5 x 1.5/5 x 2.5 mm2
V-M20-VENT
120814
1 off
Ventilation cable glands IP56
• Permeable to air, impermeable to dust
• For the prevention of condensation
For use in the enclosure bottom or sides, polyamide, halogen-free
M20
20.5
–
–
STB-M20F
224557
20 off
M25
25.5
–
–
STB-M25F
224558
20 off
MFD, MFV, STB-Zoll, V-M20-VENT, STB-M
