Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

64 / 543

16/60 Busbar system
2010 CA08103002Z-EN
SASY
D busbar mounting fuse devices
D02-SO/63/3-R-27 Z-D02/R/3-36 Z-D02/R/3-54
① Front plate support
DII-SO/25/3-R(-PS)
DIII-SO/63/3-R(-PS)
Z-D02-S-AB-SET
① Front plate support
② Covered busbar support
60
60
27 27 10
178 193 194 201
34.5
14
32
h50 36 36
a
54
a
54
a
60
60 194
31.5
200
12-30
30
b 32
35
Part no. a b
DII-SO/25/3-R(-PS) 45 5-10
DIII-SO/63/3-R(-PS) 54 5-10
36 36
a a
b
D02, DII, DIII
