IZM circuit-breakers, IN switch-disconnectors

Basic devices IZM26

2010 CA08103002Z-EN

18/121

IN63, IZM63 Fixed mounted

IN63…F, IZM63…F

IN63, IZM63 Withdrawable units

IN63…W, IZM63…W

① Recommended minimum enclosure size (not shown to scale)

349

418

394

257

78

32

887 (3p), 1141 (4p)

133

340

907 (3p), 1161 (4p)

521

432

458

129

474

482

559

908 (3p), 1162 (4p)

434

1000 (3p), 1250 (4p)

435

400

431

a

IZM26, IN26
