18/118 IZM circuit-breakers, IN switch-disconnectors
Communication modules
2010 CA08103002Z-EN
Communicationmodules
IZMX-PCAM IZMX-MCAM IZM-PMINT IZM-MMINT
General
Dimensions (W x H x D) 24 x 105 x 80 mm 24 x 105 x 80 mm 91 x 111 x 88 mm 92 x 111 x 88 mm
Mounting Auxiliary contact strip or
35 mm top-hat rail
Auxiliary contact strip or
35 mm top-hat rail
DIN rail (top hat rail) 35 mm DIN rail (top hat rail) 35 mm
Protection type IP20 IP20 IP20 IP20
Mounting position – – horizontal horizontal
Power supply 24 V DC 24 V DC 24 - 150 V DC or
100 - 240 V AC (50/60 Hz)
24 - 125 V DC or
120 V AC (50/60 Hz)
LED indicators DP Tx Rx
Status
Modbus Tx Rx
Status
DP Status
INCOM Rx Tx
Status
Modbus Tx Rx
INCOM Rx Tx
Status
Network
INCOM – – Plug-in screw terminals Plug-in screw terminals
PROFIBUS SUB-D 9-pole, socket – SUB-D 9-pole, socket –
Modbus – Plug-in screw terminals – Plug-in screw terminals
Function Slave Slave Slave Slave
Interface RS484 RS485 RS484 RS485
Protocol PROFIBUS-DP Modbus-RTU PROFIBUS-DP Modbus-RTU
Baud rate Automatic search up
to 12 MBit/s
1200/4800/9600/19200 Bit/s,
adjustable via Digitrip
Automatic search up
to 12 MBit/s
1200/9600/19200 bits/s,
adjustable through coding
switch
Bus terminating resistors In plug as required 121 Ω, externally switch-
able
In plug as required 121 Ω, activated through
coding switch
INCOM1) – – 100 Ω, activated through
coding switch
100 Ω, activated through
coding switch
Bus addresses 1 - 127,
can be set through Digitrip
1 - 247,
can be set through Digitrip
1 - 127 1 - 127
Number of IZM26
devices on INCOM
– – 1 32
Maximum distance 2.4 km 1.2 km 2.4 km 1.2 km
INCOM – – 3 3
Supported functions Cyclical data transfer Function code:
03 = read register
04 = read word variables
08 = connection test,
16 = write register
Cyclical data transfer Function code:
03 = read register
04 = read word variables
08 = connection test,
16 = write register
Notes 1) INCOM = system bus (communication connection between Digitrip and fieldbus module)
IZMX-PCAM, IZMX-MCAM, IZM-PMINT, IZM-MMINT
