IZM circuit-breakers, IN switch-disconnectors
Accessories for IZM26
2010 CA08103002Z-EN
18/117
Under-voltage releases
IZM-UVR24DC IZM-UVR32DC IZM-UVR48DC IZM-UVR60DC
Rated control voltage
AC 50/60 Hz Us V – – – –
DC Us V 24 32 48 60
Power consumption
AC VA – – – –
DC W 18 (pick-up 250) 15 (pick-up 275) 18 (pick-up 275) 18 (pick-up 275)
Response time of the
circuit-breaker with U s
ms 70 70 70 70
Operating range
Drop-out voltage
AC operated 50/60 Hz Drop-out x Uc Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard
pick-up voltage
pick-up x U c Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard
Under-voltage releases
IZM-UVR110AC IZM-UVR110DC IZM-UVR220DC IZM-UVR230AC IZM-UVR400AC
Rated control voltage
AC 50/60 Hz Us V 110 - 127 – – 208 - 240 380 - 415
DC Us V – 110 - 125 220 - 250 – –
Power consumption
AC VA 10 (pick-up 450) – – 10 (pick-up 400) 10 (pick-up 480)
DC W – 10 (pick-up 450) 10 (pick-up 450) – –
Response time of the
circuit-breaker with U s
ms 70 70 70 70 70
Operating range
Drop-out voltage
AC operated 50/60 Hz Drop-out x Uc Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard
pick-up voltage
pick-up x U c Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard Acc. to IEC standard
Motor operator
IZM-M24DC IZM-M48DC IZM-M60DC IZM-M110DC IZM-M220DC IZM-M110AC IZM-M230AC
Rated control voltage
AC 50/60 Hz Us V – – – – – 110 - 127 208 - 240
DC Us V 24 48 60 110 - 125 220 - 250 – –
Necessary time required for
charging of the spring-operated
stored energy mechanism at 1 x Us
s 5 5 5 5 5 5 5
Rated operational
current In A 12 5 5 2 1 2 1
Starting current A 36 25 25 12 6 12 6
Power consumption
AC 50/60 Hz VA 300 250 250 250 250 250 250
DC W 300 250 250 250 250 250 250
IZM-UVR..., IZM-M...
