Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

457 / 543

2010 CA08103002Z-EN
Circuit-breakers, fuses
Miniature circuit-breakers, residual-current circuit-breakers
19/3
Basic devices
FAZ miniature circuit-breakers 1
Characteristic/rated operational current
ranges
B/4 – 63 A; C/0.5 – 63 A; D/6 – 40 A;
K/0.5 - 63 A; S/1 - 40 A; Z/0.5 - 63 A
Switching capacity:
15 kA to IEC/EN 60947-2
B, C, D, K, S, Z characteristic
1-, 1N-, 2-, 3-, 3N-, 4 pole
Special miniature circuit-breaker for
control circuits (1, 2 pole)
Special miniature circuit-breaker for DC
applications up to 500 V DC
￫Page 19/4
FAZT miniature circuit-breakers 1
Characteristic/rated operational current
ranges
B/1 - 25 A; C/1 - 25 A; D/1 - 16 A
Switching capacity:
25 kA to IEC/EN 60947-2
￫Page 19/10
FAZ-PN miniature circuit-breaker 2
Characteristic/rated operational current
ranges
B/6 – 40 A; C/2 – 40 A
Switching capacity:
6 kA to IEC/EN 60898
B, C characteristic
1 N pole
￫Page 19/12
Residual-current protective modules
for fitting to FAZ 3
Protection in the event of fault current
Rated current ranges 40 – 63 A
Rated fault current 30 mA, 300 mA
￫Page 19/16
Residual-current protective modules
for fitting to AZ 12
Protection in the event of fault current
Rated current ranges 80 – 125 A
Rated fault current 30 mA, 300 mA
￫Page 19/16
PKNM combined device 4
Overload and short-circuit protection,
and protection in the event of fault
currents
Characteristic/rated operational current
ranges
B/6-40 A; C/6-40 A; 1N pole
Switching capacity:
10 kA to IEC/EN 60898
Rated fault current 30 mA, 300 mA
￫Page 19/17
Residual-current circuit-breaker
(RCCB) 5
AC current sensitive
2 pole, 16 – 80 A
4 pole, 25 – 80 A
Pulsed current sensitive
2 pole, 16 – 40 A
4 pole, 25 – 125 A
AC/DC sensitive
4 pole, 40 – 125 A
Rated fault current
30 mA, 100 mA, 300 mA, 500 mA
4 pole, selective, 63 – 80 A
Rated fault current
100 mA, 300 mA
4 pole suitable for frequency inverters
40, 63 A, 100 mA, 300 mA
￫Page 19/13
AZ miniature circuit-breakers 6
Characteristic/rated operational current
ranges C/20-125 A; D/50-100 A
Switching capacity: 15 – 25 kA to
IEC/EN 60947-2, 1-, 2-, 3-, 3N-, 4 pole
￫Page 19/14
Add-on functions
FAZ auxiliary contact 7
Standard auxiliary contact
Trip-indicating auxiliary contacts
Auxiliary contacts
￫Page 19/24
AZ auxiliary contact 8
Standard auxiliary contacts
￫Page 19/24
FAZ shunt releases 9
Undervoltage release
Shunt releases
Can be fitted to FAZ or FAZ‐FIM
￫Page 19/24
AZ shunt releases 10
Shunt releases
￫Page 19/24
FI auxiliary contact 13
Auxiliary contacts
￫Page 19/24
Remote switching module 11
Suitable for remote switching and
automatic restart of a miniature circuit-
breaker or RCCB, for remote trip testing
of an RCCB in conjunction with a remote
test module
￫Page 19/22
