17/74 Circuit-breakers, switch-disconnectors
Circuit-breakers UL/CSA, IEC magnetic short-circuit releases, 3 pole
2010 CA08103002Z-EN
www.eaton.comCircuit-breakersUL/CSA, IECmagnetic short-circuit releases, 3pole
Fixed mounting
with screw terminals
Rated current =
Rated uninterrupted current
Setting range
Part no.
Article no.
Price
See price
list
Std. pack
Short-circuit releases
I
n
= I
u
Non-delayed
A
I
i
= I
n
x …
Short-circuit protection
Motor protection in conjunction with contactor and overload relay
• With short-circuit release
• Without overload release I
r
Normal switching capacity
1.2
7-12
1)
NZMN1-S1.2-CNA
103025
B 1 off
2
6-11
NZMN1-S2-CNA
103026
B
3
6-11
NZMN1-S3-CNA
103027
B
5
6-11
NZMN1-S5-CNA
103028
B
8
6-11
NZMN1-S8-CNA
103029
B
12
7-12
NZMN1-S12-CNA
103030
B
18
7-12
NZMN1-S18-CNA
103031
B
26
8-13
NZMN1-S26-CNA
103032
B
33
8-14
NZMN1-S33-CNA
103033
B
40
8-14
NZMN1-S40-CNA
281276
B
50
8-14
NZMN1-S50-CNA
281277
B
63
8-14
NZMN1-S63-CNA
281278
B
80
8-14
NZMN1-S80-CNA
281279
B
100
8-13
NZMN1-S100-CNA
281280
B
1.6
8-14
2)
NZMN2-S1.6-CNA
269478
S
2.4
8-14
NZMN2-S2.4-CNA
269479
S
5
6-11
NZMN2-S5-CNA
103040
S
8
6-11
NZMN2-S8-CNA
103041
S
12
7-12
NZMN2-S12-CNA
103042
S
18
7-12
NZMN2-S18-CNA
103043
S
26
8-13
NZMN2-S26-CNA
103044
S
33
8-14
NZMN2-S33-CNA
103045
S
40
8-14
NZMN2-S40-CNA
269255
S
50
8-14
NZMN2-S50-CNA
269256
S
63
8-14
NZMN2-S63-CNA
269257
S
80
8-14
NZMN2-S80-CNA
269258
S
100
8-14
NZMN2-S100-CNA
269259
S
125
8-14
NZMN2-S125-CNA
269260
S
160
8-14
NZMN2-S160-CNA
269261
S
200
8-13
NZMN2-S200-CNA
269262
S
250
8-10
NZMN2-S250-CNA
102479
S
I
NZM...-S...CNA
