Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

169 / 543

2010 CA08103002Z-EN
Circuit-breakers, switch-disconnectors
Circuit-breakers UL/CSA, IEC magnetic short-circuit releases, 3 pole
Fixed mounting
with box terminals
Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America Notes
B = box terminals
S = screw terminals
For further terminal types see
accessories
NZMB1-S1.2-CNA
102906
B 1 off Product Standards UL 489; CSA-C22.2 No. 5-09; IEC
60947-2; CE marking
UL File No. E31593
UL CCN DKPU2
CSA File No. 022086
CSA Class No. 1432-01
NA Certification UL Recognized, CSA certified
Conditions of Acceptability Only used in motor circuits in
conjunction with suitable
contactor and overload relay.
SCCR value applies for complete
combination starter only,
consisting of instantaneous trip
circuit breaker, contactor and
overload relay.
Specially designed for NA Yes
Suitable for Branch circuits, feeder circuits
Max. Voltage Rating 480Y/277 V
Degree of Protection IEC: IP20; UL/CSA Type: -
Switches correspond with both
UL/CSA and IEC regulations. IEC
switching performance values
shown on type label.
NZMB1-S2-CNA
102907
B
NZMB1-S3-CNA
102908
B
NZMB1-S5-CNA
102909
B
NZMB1-S8-CNA
103020
B
NZMB1-S12-CNA
103021
B
NZMB1-S18-CNA
103022
B
NZMB1-S26-CNA
103023
B
NZMB1-S33-CNA
103024
B
NZMB1-S40-CNA
281263
B
NZMB1-S50-CNA
281264
B
NZMB1-S63-CNA
281265
B
NZMB1-S80-CNA
281266
B
NZMB1-S100-CNA
281267
B
NZMB2-S1.6-BT-CNA
107651
B 1 off Product Standards UL 489; CSA-C22.2 No. 5-09; IEC
60947-2; CE marking
UL File No. E31593
UL CCN DKPU2
CSA File No. 022086
CSA Class No. 1432-01
NA Certification UL Recognized, CSA certified
Conditions of Acceptability Only used in motor circuits in
conjunction with suitable
contactor and overload relay.
SCCR value applies for complete
combination starter only,
consisting of instantaneous trip
circuit breaker, contactor and
overload relay.
Specially designed for NA Yes
Suitable for Branch circuits, feeder circuits
Max. Voltage Rating 600Y/347 V, 480 V
Degree of Protection IEC: IP20; UL/CSA Type: -
NZMB2-S2.4-BT-CNA
107652
B
NZMB2-S5-BT-CNA
107653
B
NZMB2-S8-BT-CNA
107654
B
NZMB2-S12-BT-CNA
107655
B
NZMB2-S18-BT-CNA
107656
B
NZMB2-S26-BT-CNA
107657
B
NZMB2-S33-BT-CNA
107658
B
NZMB2-S40-BT-CNA
107659
B
NZMB2-S50-BT-CNA
107660
B
NZMB2-S63-BT-CNA
107661
B
NZMB2-S80-BT-CNA
107662
B
NZMB2-S100-BT-CNA
107663
B
NZMB2-S125-BT-CNA
107664
B
NZMB2-S160-BT-CNA
107665
B
NZMB2-S200-BT-CNA
107666
B
NZMB2-S250-BT-CNA
107667
B
17/73
NZM...-S...CNA HPL17073EN
