Circuit-breakers, switch-disconnectors
Circuit-breakers UL/CSA, IEC, electronic releases, 3 pole
NZMH2-VEF150-BT-NA
107598
B 1 off Product Standards UL 489; CSA-C22.2 No. 5-09; IEC
60947-2; CE marking
UL File No. E31593
UL CCN DIVQ
CSA File No. 022086
CSA Class No. 1432-01
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Feeder circuits, branch circuits
Current Limiting CB Yes
Max. Voltage Rating 600Y/347 V, 480 V
Degree of Protection IEC: IP20; UL/CSA Type: -
IEC switching performance values shown on
type label.
Adjustable delay setting t r
• 2 – 20 s at 6 x Ir
Adjustable delay t sd
• Steps 0, 20, 60, 100, 200, 300, 500,
750, 1000 ms
i 2t constant function
• NZM2 fixed OFF
• NZM3, NZM4 switchable (ex-works OFF)
NZMH2-VEF175-BT-NA
107599
B
NZMH2-VEF200-BT-NA
107840
B
NZMH2-VEF225-BT-NA
107841
B
NZMH2-VEF250-BT-NA
107842
B
Terminals as accessory 1 off Product Standards UL 489; CSA-C22.2 No. 5-09; IEC
60947-2; CE marking
UL File No. E31593
UL CCN DIVQ
CSA File No. 022086
CSA Class No. 1432-01
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Feeder circuits, branch circuits
Current Limiting CB Yes
Max. Voltage Rating 600 V
Degree of Protection IEC: IP20; UL/CSA Type: -
Terminals as accessory
Fixed mounting
with box terminals
Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America Notes
17/69
NZM...VEF...NA HPL17069EN
