Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

167 / 543

2010 CA08103002Z-EN
Circuit-breakers, switch-disconnectors
Circuit-breakers UL/CSA, IEC, electronic releases, 3 pole
Fixed mounting
with box terminals
Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America Notes
NZMN2-VE100-BT-NA
107843
B 1 off Product Standards UL 489; CSA-C22.2 No. 5-09;
IEC 60947-2; CE marking
UL File No. E31593
UL CCN DIVQ
CSA File No. 022086
CSA Class No. 1432-01
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Feeder circuits, branch circuits
Current Limiting CB Yes
Max. Voltage Rating 600Y/347 V, 480 V
Degree of Protection IEC: IP20; UL/CSA Type: -
Switches correspond with both UL/CSA and IEC
regulations. IEC switching performance values
shown on type label.
Adjustable delay setting tr
• 2 – 20 s at 6 x Ir
Adjustable delay tsd
• Steps: 0, 20, 60, 100, 200, 300, 500, 750, 1000 ms
i2t constant function
• NZM2 fixed OFF
• NZM3, NZM4 switchable (ex-works OFF)
NZMN2-VE160-BT-NA
107844
B
NZMN2-VE250-BT-NA
107845
B
Terminals as accessory Product Standards UL 489; CSA-C22.2 No. 5-09;
IEC 60947-2; CE marking
UL File No. E31593
UL CCN DIVQ
CSA File No. 022086
CSA Class No. 1432-01
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Feeder circuits, branch circuits
Current Limiting CB Yes
Max. Voltage Rating 600 V
Degree of Protection IEC: IP20; UL/CSA Type: -
NZMH2-VE100-BT-NA
107846
B 1 off Product Standards UL 489; CSA-C22.2 No. 5-09;
IEC 60947-2; CE marking
UL File No. E31593
UL CCN DIVQ
CSA File No. 022086
CSA Class No. 1432-01
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Feeder circuits, branch circuits
Current Limiting CB Yes
Max. Voltage Rating 600Y/347 V, 480 V
Degree of Protection IEC: IP20; UL/CSA Type: -
NZMH2-VE160-BT-NA
107847
B
NZMH2-VE250-BT-NA
107848
B
Terminals as accessory Product Standards UL 489; CSA-C22.2 No. 5-09;
IEC 60947-2; CE marking
UL File No. E31593
UL CCN DIVQ
CSA File No. 022086
CSA Class No. 1432-01
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Feeder circuits, branch circuits
Current Limiting CB Yes
Max. Voltage Rating 600 V
Degree of Protection IEC: IP20; UL/CSA Type: -
17/71
NZM...VE...NA HPL17071EN
