173 / 543
2010 CA08103002Z-EN
www.eaton.comCircuit-breakers, switch-disconnectors
Circuit-breakers UL/CSA, IEC, electronic releases, 3 pole
Fixed mounting
with box terminals
Part no.
Article no.
Price
See Price
list
Std. pack
Information relevant for export to North America
Notes
B = box terminals
S = screw terminals
For further terminal types see
accessories
NZMN2-ME90-BT-NA
142421
S 1 off
Product Standards
UL 489; CSA-C22.2 No. 5-09;
IEC 60947-2; CE marking
UL CCN
DIVQ
NA Certification
Request filed for UL and CSA
Specially designed for NA Yes, additionally calibrated
according to UL 508
Suitable for
Feeder circuits, branch
circuits
Max. Voltage Rating
480 V
Degree of Protection
IEC: IP20; UL/CSA Type: -
Switches correspond with both UL/CSA
and IEC regulations. IEC switching
performance values shown on type label.
Adjustable delay setting t
r
• 2 – 20 s at 6 x I
r
NZMN2-ME140-BT-NA
142422
S
NZMN2-ME200-BT-NA
142423
S
NZMH2-ME90-BT-NA
142424
S
1 off
NZMH2-ME140-BT-NA
142425
S
NZMH2-ME200-BT-NA
142426
S
17/77
NZM...ME...NA, NZM...SE...CNA
HPL17077EN
Fixed mounting
with screw terminals
Rated current =
Rated uninter-
rupted current
Setting
range
Part no.
Article no.
Price
See price
list
Std. pack
Information relevant for export to North America Notes
Short-
circuit
releases
I
n
= I
u
Non-
delayed
A
I
i
= I
n
x …
Short-circuit protection
Motor protection in conjunction with
contactor and overload relay
• With short-circuit release
• Without overload release
Ir
B = box terminals
S = screw terminals
For further terminal types
see accessories
Normal switching capacity
220
2-14
NZMN3-SE220-CNA
269341
S 1 off
Product Standards
UL 489; CSA-C22.2 No.
5-09; IEC 60947-2; CE
marking
UL File No.
E31593
UL CCN
DKPU2
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Recognized, CSA
certified
Conditions of Acceptability Only used in motor
circuits in conjunction
with suitable contac-
tor and overloadrelay.
SCCR value applies
for complete combi-
nation starter only,
consisting of instanta-
neous trip circuit
breaker, contactor
and overload relay.
Specially designed for NA Yes
Suitable for
Branch circuits,
feeder circuits
Max. Voltage Rating
600 V
Degree of Protection
IEC: IP20; UL/CSA
Type: -
Switches
correspond with
both UL/CSA and
IEC regulations.
IEC switching
performance
values shown on
type label.
350
2-14
NZMN3-SE350-CNA
269342
S
450
2-12
NZMN3-SE450-CNA
284465
S
I
