17/80 Circuit-breakers, switch-disconnectors
Molded case switches for North America
2010 CA08103002Z-EN
Moldedcase switches forNorthAmerica
Fixed mounting
with screw terminals
Rated current = Rated
uninterrupted current
Switching capacity Response
value of
short-circuit
releases
Part no.
Article no.
Price
See price
list SCCR
480Y/
277 V
60 Hz
SCCR
480 V
60 Hz
SCCR
600Y/
347 V
60 Hz
SCCR
600 V
60 Hz
In = Iu Icu Icu Icu Icu Ii
A kA kA kA kA A
Molded case switches for North America
With permanently set short-circuit release (self-protection)
3 switch positions I, +, 0
Can be remotely operated with shunt release XU/XA, remote operator XR,
Can be equipped with trip-indicating auxiliary contact M22-K..
63 35 – – – 1250 Screw
terminals as
accessories
100 – – 1250
125 – – 1250
160 100 100 50 – 2500 NS2-160-NA
102684
S
200 2500 NS2-200-NA
102685
S
250 2500 NS2-250-NA
102686
S
400 100 100 50 50 6600 NS3-400-NA
102687
S
600 6600 NS3-600-NA
102688
S
800 65 65 42 42 25000 NS4-800-NA
102689
S
1000 25000 NS4-1000-NA
102690
S
1200 25000 NS4-1200-NA
102691
S
NS...NA HPL17080EN
