17/82 Circuit-breakers, switch-disconnectors
Terminals
2010 CA08103002Z-EN
Terminals
Max. cable
connection area
Number of
poles
For use with Terminal capacity Terminal capacity
Cable
Cable lugs
Terminal
capacity
AWG/kcmil Copper strip
No. of discs ×
width × disc
thickness
Copper bar
width x
thickness
mm² mm mm
Box terminal
Standard equipment
3 pole NZM1,
PN1,
N(S)1
Copper cable 1 x 10 - 70
2 x 6 - 25
1)
1 x 12 - 2/0 ≧ 2 x 9 x 0.8 –
4 pole NZM1-4,
PN1-4,
N1-4
Screw terminals
3 pole NZM1,
PN1,
N(S)1
Copper cable
lugs
Aluminiumcable
lugs
1 x 10 - 70
2 x 6 - 25
1 x 10 - 35
2 x 10 - 35
1)
1 x 12 - 2/0 – ≧ 12 x 5
4 pole NZM1-4,
PN1-4,
N1-4
Tunnel terminal
3 pole NZM1,
PN1,
N(S)1
Copper
cable  
Aluminium
cable  
1 x 16 - 95
1)
1 x 6 - 3/0
-
– –
4 pole NZM1-4,
PN1-4,
N1-4
Rear terminal bolts
Not UL/CSA approved
– 3 pole NZM1,
PN1,
N1
Copper cable
lugs
Aluminiumcable
lugs
1 x 10-70
2 x 6-25
1 x 10-35
2 x 10-35
1)
– – min. 12 x 5
max. 16 x 5
– 4 pole NZM1-4,
PN1-4,
N1-4
Notes 1) Up to 95 mm2 can be connected depending on make of cable.
10
12
7
o 6.5
16
14.5
NZM1 HPL17082EN
