13/12 Safety relays
Basic devices
2010 CA08103002Z-EN
Safety
ES4P…
NET network
Stations Number Max. 8
Data transfer rate/distance 1000 Kbit/s, 6 m
500 Kbit/s, 25 m
250 Kbit/s, 60 m
125 Kbit/s, 125 m
50 Kbit/s, 300 m
20 Kbit/s, 700 m
10 Kbit/s, 1000 m
Bus lengths greater than 40 m can only be achieved with enhanced
cross-section conductors and terminal adapters.
Potential isolation
From power supply Yes
From the inputs Yes
From the outputs Yes
From the PC interface, memory card, NET network, EASY-Link Yes
Bus termination (first and last station) Yes
Terminal type RJ45
Digital inputs 24 V DC
Number 14
Inputs can be used as analog inputs -
Status display LCD display (if provided)
Potential isolation
From power supply No
Between digital inputs No
From the outputs Yes
From PC interface, memory card, easyLink No
From network easyNet Yes
Rated operational voltage Ue V DC 24
At signal ”0” Ue V DC < 5
At signal ”1” Ue V DC > 15
Clock outputs
Number 4
Voltage V DC 24
Electrical isolation No
Relay outputs
Number 4 for ES4P-...-DR..
1 redundant for ES4P-…-DM…
Outputs in groups of 1
Parallel switching of outputs to increase power Not permissible
Protection of an output relay Fuse: 6 A gG,
Circuit-breaker with characteristic C: 24 V DC 4 A,
Short-circuit current < 250 A
Potential isolation
From power supply Yes
From the inputs Yes
From PC interface, memory card, easyNet, easyLink Yes
Safe isolation according to EN 50178 V AC 300
Basic insulation V AC 600
Lifespan, mechanical Operations x 106 10
Contacts
Conventional thermal current A 6
Rated impulse withstand voltage Uimp contact coil kV 6
Rated operational voltage Ue V AC 250
Rated insulation voltage Ui V AC 250
Safe isolation to EN 50178 between coil and contact V AC 300
Making capacity
AC-15, 230 V AC, 3 A Operations 80000
DC-13, 24 V DC, 5 A, 0,1 Hz Operations 40000
Switching frequency
Mechanical operations x 106 10
Switching frequency Hz 10
UL/CSA
UL 508 B300/R300
