13/10 Safety relays
Accessories
2010 CA08103002Z-EN
Safety
Supply voltage Description Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
PROFIBUS-DP data cable
Twisted pair, without plug, 2-core,
2 x 0.64 mm²
(only suitable for fixed wiring)
100 m
ZB4-900-KB1
206983
100 m
PROFIBUS-DP bus connector plug
Pins, 9 pole
Cable entry, angled 90°
ZB4-209-DS2
206982
1 off
Metallised insulated housing
Maximum transfer rate 12 MBit/s
Integrated switch (accessible from the
outside) for the bus terminating
resistors
Terminal block for two cable entries,
with straight or 90° angled cable entry,
as required
ZB4-209-DS3
217820
1 off
Connection plug
Bus connector plug between base unit
and expansion unit/bus module
EASY-LINK-DS
221607
1 off UL/CSA certification not required
Fixing bracket
For screw fixing to mounting plate
2 fixing brackets per easy200
3 fixing brackets per easy400, 500, 600,
800, ES4P, EC4P, MFD(-AC)-CP8...
ZB4-101-GF1
061360
9 off UL/CSA certification not required
Telescopic clip
With 35mm top-hat rail to IEC/EN 60715
for mounting depth compensation when
rear mounting in CI-K…enclosures and
cabinets.
Stepless adjustment via scale from
75 – 115 mm.
Screw and snap mounting
M22-TA
226161
1 off Product Standards IEC/EN 60947-5; UL 508;
CSA-C22.2 No. 14-05;
CSA-C22.2 No. 94-91;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Top-hat rail adapter for inspection window
12 mm x 66 mm x 82 mm
Installation on hinged inspection
window, for front fitting of devices.
Complete set, consisting of 2 brackets
and 4 screws
SKF-HA
233782
1 off UL/CSA certification not required
Inspection window
130 mm x 77 mm x 25 mm (6 space units)
For use with EASY700, EASY800, EC4P,
ES4P
SKF-FF6
233781
1 off UL/CSA certification not required
