Eaton Industrial Switchgear - xStart switching, protections and actuating motors

8 / 439

5/4 Contactors
Mini contactor relays
2010 CA08103002Z-EN
Rated
operational
current
Max. motor rating for
three-phase motors, 50 - 60 Hz
Conventional thermal
current Ith = Ie
AC-1 at 50 °C
Contact Circuit symbol For use with
AC-3 AC-3 AC-4
380 V
400 V
220 V
230 V
380 V
400 V
660 V
690 V
220 V
230 V
380 V
400 V
660 V
690 V
Open Enclosed N/O =normallyopen
contact
NC = normally
closed contact
Ie P P P P P P Ith = Ie Ith = Ie
A kW kW kW kW kW kW A A
DILEM contactors
3 pole with auxiliary contact
Screw terminals
6.6 1.5 3 3 1.1 2.2 2.2 20 16 1 N/O – …DILEM
DILE…
6.6 1.5 3 3 1.1 2.2 2.2 20 16 – 1 NC DILE…
9 2.2 4 4 1.5 3 3 20 16 1 N/O – …DILEM
DILE…
9 2.2 4 4 1.5 3 3 20 16 – 1 NC DILE…
12 3.5 5.5 6.5 2 3 2.2 20 16 1 N/O – …DILEM
DILE…
12 3.5 5.5 6.5 2 3 2.2 20 16 – 1 NC DILE…
4 pole
Screw terminals
9 2.2 4 4 1.5 3 3 20 16 – – …DILEM
DILE…
1) 2)
Information relevant for export to North America Information relevant for export to North America
Product Standards
IEC/EN 60947-4-1;
UL 508; CSA-C22.2
No. 14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 012528
CSA Class No. 3211-04
NA Certification UL Listed, CSA certified
See also ￫Page 5/84
Product Standards
IEC/EN 60947-4-1;
UL 508; CSA-C22.2 No. 14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 012528
CSA Class No. 2411-03, 3211-04
NA Certification UL Listed, request filed for CSA
2
3 5
4 6
A1
A2
1 13
14
2
3 5
4 6
A1
A2
1 21
22
2
3 5
4 6
A1
A2
1 13
14
2
3 5
4 6
A1
A2
1 21
22
2
3 5
4 6
A1
A2
1 13
14
2
3 5
4 6
A1
A2
1 21
22
2
3 5
4 6
A1
A2
1 7
8
DILEM HPL05004EN
