Eaton Industrial Switchgear - xStart switching, protections and actuating motors

6 / 439

5/2 Contactors
Mini contactor relays
2010 CA08103002Z-EN
Minicontactor relaysOrdering
Rated operational current Conventional free
air thermal current
Contact Distinctive
number
Circuit symbol For use with
AC-15 N/O = normally open contact
NC = normally closed contact
220 V
230 V
240 V
380 V
400 V
415 V
Ie Ie Ith
A A A
DILER mini contactor relays
Screw terminals
6 3 10 4 N/O – 40E DILE…
3 N/O 1 NC 31E DILE…
2 N/O 2 NC 22E DILE…
Notes Coil terminal marking as specified in EN 50005
Contact numbers to EN 50011
The following applies to DC-operated contactors:
• Integrated diode-resistor combination
• Coil rating 2.6 W
Information relevant for export to North America
Product Standards
IEC/EN 60947-4-1; UL 508; CSA-C22.2 No. 14-05;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed,
CSA certified
14
13 33
34
43
44
A1
A2
23
24
14
13 21
22
33
34
43
44
A1
A2
14
13 21
22
31
32
43
44
A1
A2
DILER HPL05002EN
