Frequency inverters
H-Max™ Frequency inverter
2010
CA08103002Z-EN
www.eaton.com10/11
Rated operational voltage 3 AC 230 V
77
18.5
63
HMX32AG07721-B
127162
1
off
HMX32AG07722-B
127181
1
off
88
22
71
HMX32AG08821-B
127163
HMX32AG08822-B
127182
106
30
96
HMX32AG10621-B
127164
HMX32AG10622-B
127183
143
45
117
HMX32AG14321-B
127165
HMX32AG14322-B
127184
170
45
141
HMX32AG17021-B
127166
HMX32AG17022-B
127185
208
55
173
HMX32AG20821-B
127167
HMX32AG20822-B
127186
261
75
233
HMX32AG26121-B
127168
HMX32AG26122-B
127187
310
90
279
HMX32AG31021-B
127169
HMX32AG31022-B
127188
Notes
1)
Rated operational current at an operating frequency of 6 kHz and an ambient temperature of +40 °C
2)
Assigned motor rating for normal internally and externally ventilated four-pole, three-phase asynchronous motors with 1500 rpm
(
at 50 Hz) or 1800 rpm (at 60 Hz)
Information relevant for export to North America
Product Standards UL 508C; CSA-C22.2 No. 14; IEC/EN61800-3; IEC/EN61800-5; CE marking
NA Certification
Request filed for UL and CSA
Suitable for
Branch circuits
Max. Voltage Rating 3~ 240 V AC IEC: TN-S UL/CSA: "Y" (Solidly Grounded Wey)
Degree of Protection IEC: IP21; UL/CSA NEMA 1
With internal radio
interference
suppression filter,
protection type IP21
With internal radio
interference
suppression filter,
protection type IP54
Rated opera-
tional current
of frequency
inverter
1)
Assigned
motor rating
(50/60
Hz)
2)
Rated
operational
current motor
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
I
e
P
I
e
A
kW
A
HMX32...HMX34...
