H-Max™
H-Max™System overview
3
4
1
2
Basic device
Frequency inverters 1
HMX32…
Mains: 3-phase, 230/240 V
Assigned motor rating
from 0.75 to 90 kW (230 V)
￫Page 10/10
HMX34…
Mains: 3-phase, 400/480 V
Assigned motor rating
from 1.1 to 160 kW (400 V)
￫Page 10/12
System accessories
Communication module 4
Versions
• CANopen fieldbus connection
• PROFIBUS DP fieldbus connection
• DeviceNet fieldbus connection
￫Page 10/18
Accessories
Motor chokes 2
￫Page 10/21
Braking resistor 3
￫Page 10/17
