Frequency inverters
H-Max™ Frequency inverter
2010
CA08103002Z-EN
www.eaton.comH-Max™ Frequency inverter
Ordering
With internal radio
interference
suppression filter,
protection type IP21
With internal radio
interference
suppression filter,
protection type IP54
Rated opera-
tional current
of frequency
inverter
1)
Assigned
motor rating
(50/60
Hz)
2)
Rated
operational
current motor
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
I
e
P
I
e
A
kW
A
Rated operational voltage 3 AC 230 V
3.7
0.55
2.7
HMX32AG3D721-B
127151
1
off
HMX32AG3D722-B
127170
1
off
4.8
0.75
3.2
HMX32AG4D821-B
127152
HMX32AG4D822-B
127171
6.6
1.1
4.6
HMX32AG6D621-B
127153
HMX32AG6D622-B
127172
8
1.5
6.3
HMX32AG8D021-B
127154
HMX32AG8D022-B
127173
11
2.2
8.7
HMX32AG01121-B
127155
HMX32AG01122-B
127174
12.5
3
11.5
HMX32AG01221-B
127156
HMX32AG01222-B
127175
18
4
14.8
HMX32AG01821-B
127157
1
off
HMX32AG01822-B
127176
1
off
24.2
5.5
19.6
HMX32AG02421-B
127158
HMX32AG02422-B
127177
31
7.5
26.4
HMX32AG03121-B
127159
HMX32AG03122-B
127178
48
11
38
HMX32AG04821-B
127160
1
off
HMX32AG04822-B
127179
1
off
62
15
51
HMX32AG06221-B
127161
HMX32AG06222-B
127180
Notes
1)
Rated operational current at an operating frequency of 6 kHz and an ambient temperature of +40 °C
2)
Assigned motor rating for normal internally and externally ventilated four-pole, three-phase asynchronous motors with 1500 rpm
(
at 50 Hz) or 1800 rpm (at 60 Hz)
Information relevant for export to North America
Product Standards UL 508C; CSA-C22.2 No. 14; IEC/EN61800-3; IEC/EN61800-5; CE marking
NA Certification
Request filed for UL and CSA
Suitable for
Branch circuits
Max. Voltage Rating 3~ 240 V AC IEC: TN-S UL/CSA: "Y" (Solidly Grounded Wey)
Degree of Protection IEC: IP21; UL/CSA NEMA 1
I
OK
BACK
RESET
LOC
REM
I
OK
BACK
RESET
LOC
REM
I
OK
BACK
RESET
LOC
REM
HMX32...
