DM4 soft starters
Accessories
2010
CA08103002Z-EN
www.eaton.com9/45
Rated
operational
current
Maximum
power loss
Frame size/
inside
micrometer
For use with
Part no.
Article no.
Price
See price list
Std. pack
Notes
P
v
A
W
mm
Superfast semiconductor fuses
Fuse links
40
10
80
DM4-340-7K5
20.282.20-40
232085
6
off
–
80
18
80
DM4-340-11K
DM4-340-15K
20.282.20-80
232086
6
off
–
125
24
80
DM4-340-22K
DM4-340-30K
20.282.20-125
232087
6
off
–
200
44
80
DM4-340-37K
DM4-340-45K
20.610.32-200
106475
3
off
–
350
61
80
DM4-340-55K
DM4-340-75K
20.610.32-350
221161
2
off
–
450
70
80
DM4-340-90K
DM4-340-110K
20.610.32-450
221162
2
off
Mounted internally
500
72
80
DM4-340-132K
DM4-340-160K
20.610.32-500
221163
2
off
630
80
80
DM4-340-200K
20.610.32-630
221164
3
off
900
120
80
DM4-340-250K
DM4-340-315K
20.630.32-900
221165
2
off
1250
147
80
DM4-340-400K
DM4-340-500K
20.630.32-1250
221166
2
off
Fuse base for semiconductor fuses
–
–
80
20.282.20-…
20.189.20-…
21.189.01
232064
5
off
–
–
–
80
20.6
xx.32-…
21.313.02
232076
2
off
–
Information relevant for export to North America
Product Standards UL 248-13 CE marking
UL File No.
E180276
UL CCN
JFHR2
CSA File No.
UL report applies to both US and Canada
CSA Class No.
JFHR8
NA Certification
UL Recognized, certified by UL for use in Canada
Max. Voltage Rating 660V
HPL09045EN
