DS6 soft starters
Soft starters
DS6-340-45K-MX DS6-340-55K-MX DS6-340-75K-MX DS6-340-90K-MX DS6-340-110K-MX
IEC/EN 60947-4-2 IEC/EN 60947-4-2 IEC/EN 60947-4-2 IEC/EN 60947-4-2 IEC/EN 60947-4-2
– – – – –
Damp heat, constant, according to IEC 60068-2-78, damp heat, cyclic, according to IEC 60068-2-10
0 - +40, up to 60 at 1 % derating
per Kelvin temperature rise
0 - +40, up to 60 at 1 % derating
per Kelvin temperature rise
0 - +40, up to 60 at 1 % derating
per Kelvin temperature rise
0 - +40, up to 60 at 1 % derating
per Kelvin temperature rise
0 - +40, up to 60 at 1 % derating
per Kelvin temperature rise
-25 - 55 -25 - 55 -25 - 55 -25 - 55 -25 - 55
0 - 1000, above that 1 % derating
per 100 m, to max. 2000 m
0 - 1000, above that 1 % derating
per 100 m, to max. 2000 m
0 - 1000, above that 1 % derating
per 100 m, to max. 2000 m
0 - 1000,above that 1 % derating
per 100 m, to max. 2000 m
0 - 1000, above that 1 % derating
per 100 m, to max. 2000 m
Vertical Vertical Vertical Vertical Vertical
IP20 IP20 IP20 IP20 IP20
Finger- and back-of-hand proof
II/2 II/2 II/2 II/2 II/2
8 g/11 ms 8 g/11 ms 8 g/11 ms 8 g/11 ms 8 g/11 ms
2 M2 2M2 2M2 2M2 2M2
18 25 24 30 42
93 x 175 x 139 93 x 175 x 139 108 x 215 x 178 108 x 215 x 178 108 x 215 x 178
A1 A1 A1 A1 A1
1.8 1.8 3.7 3.7 3.7
230 - 460 230 - 460 230 - 460 230 - 460 230 - 460
50/60 50/60 50/60 50/60 50/60
81 99 134 160 196
22 30 30 45 55
45 55 75 90 110
60 75 100 125 150
81 A: AC-53a: 3 - 5; 75 - 10 99 A: AC-53a: 3 - 5; 75 - 10 135 A: AC-53a: 3 - 5; 75 - 10 160 A: AC-53a: 3 - 5; 75 - 10 200 A: AC-53a: 3 - 5; 75 - 10
1 x (25 - 70)
2 x (6 - 25)
1 x (25 - 70)
2 x (6 - 25)
1 x (4 - 185)
2 x (4 - 70)
1 x (4 - 185)
2 x (4 - 70)
1 x (4 - 185)
2 x (4 - 70)
– – – – –
1 x (25 - 70)
2 x (6 - 25)
1 x (25 - 70)
2 x (6 - 25)
1 x (4 - 185)
2 x (4 - 70)
1 x (4 - 185)
2 x (4 - 70)
1 x (4 - 185)
2 x (4 - 70)
1 x (12 - 2/0) 1 x (12 - 2/0) 1 x (12 - 350 kcmil)
2 x (12 - 00)
1 x (12 - 350 kcmil)
2 x (12 - 00)
1 x (12 - 350 kcmil)
2 x (12 - 00)
2 x 9 x 0.8 2 x 9 x 0.8 2 x 9 x 0.8 2 x 9 x 0.8 2 x 9 x 0.8
9 x 9 x 0.9 9 x 9 x 0.9 10 x 16 x 0.8 10 x 16 x 0.8 10 x 16 x 0.8
– – – – –
1 x (0.5 - 2.5)
2 x (0.5 - 1.0)
1 x (0.5 - 2.5)
2 x (0.5 - 1.0)
1 x (0.5 - 2.5)
2 x (0.5 - 1.0)
1 x (0.5 - 2.5)
2 x (0.5 - 1.0)
1 x (0.5 - 2.5)
2 x (0.5 - 1.0)
1 x (0.5 - 1.5)
2 x (0.5 - 0.75)
1 x (0.5 - 1.5)
2 x (0.5 - 0.75)
1 x (0.5 - 1.5)
2 x (0.5 - 0.75)
1 x (0.5 - 1.5)
2 x (0.5 - 0.75)
1 x (0.5 - 1.5)
2 x (0.5 - 0.75)
1 x (0.5 - 1.5)
2 x (0.5 - 1.0)
1 x (0.5 - 1.5)
2 x (0.5 - 1.0)
1 x (0.5 - 1.5)
2 x (0.5 - 1.0)
1 x (0.5 - 1.5)
2 x (0.5 - 1.0)
1 x (0.5 - 1.5)
2 x (0.5 - 1.0)
1 x (21 - 14)
2 x (21 - 18)
1 x (21 - 14)
2 x (21 - 18)
1 x (21 - 14)
2 x (21 - 18)
1 x (21 - 14)
2 x (21 - 18)
1 x (21 - 14)
2 x (21 - 18)
– – – – –
0.4 0.4 0.4 0.4 0.4
0.6 x 3.5 0.6 x 3.5 0.6 x 3.5 0.6 x 3.5 0.6 x 3.5
9/13
DS6
